Featured flow transmitter manuals
Meister DKM/TA Flow Meter Datasheet
The DKM/TA series is a flow meter with analog output designed for central lubrication and oil‑circulation applications. It measures flow using a floating‑body principle and offers adjustable measurement ranges via two potentiometers.
The device operates up to 250 bar (MS) or 300 bar (VA) pressure, handles viscosities from 30 cSt to 600 cSt, and provides 4‑20 mA current or 0‑10 V voltage output. It is built to IP67 protection standards and can withstand vibration and shock conditions. This manual is written in German.
Covers: Technical Data · Measurement Principle · Application Areas · Installation Note · Technical Drawing
BOTA BT702 Flow Totalizer User Manual
The BT702 flow totalizer from BOTA is a compact instrument for measuring and accumulating flow, pressure, and temperature. It provides real‑time flow values, cumulative totals, and supports various input signal types with optional temperature and pressure compensation.
The manual details technical specifications, installation and wiring procedures, menu navigation, alarm settings, and flow‑coefficient calculations. It also includes communication options, data logging parameters, and troubleshooting guidance. This manual is written in Chinese.
Covers: 技术指标 · 安装与接线 · 操作及参数说明 · 报警说明 · 流量算法说明 · 选型说明
Guanghua Instruments Liquid Crystal Flow Meter User Manual
This guide describes the main functions of the liquid crystal flow meter, including total, class and instantaneous flow display, time/date readout, 4‑20 mA analog output, communication options, and external sensor handling. It also details the three-key keypad used for navigation, data entry, and parameter adjustments.
The document provides step‑by‑step instructions for setting flow display formats, units (L or m³, L/s or m³/h), pulse equivalents, baud rates, rotation direction, and shift‑reset options. Wiring diagrams and battery replacement procedures are included to ensure proper installation and maintenance. This manual is written in Chinese.
Covers: Function Description · Keypad Description · Display and Operation · Parameter Settings · Wiring Diagram · Battery Replacement
Latest flow transmitter manuals
ABB ST400 flow transmitter
The LST400 is an ultrasonic level transmitter capable of measuring liquid level or solid applications up to 15 m (50 ft.) or flow rates in all types of open channel flow applications. The transmitter has a single 4 to 20 mA DC analog output with HART 7 and five (5) relay outputs. A transducer is fitted to the top of a silo or tank, facing down towards the material being measured.
Meister DKM/TA Flow Meter Datasheet
Datasheet 2 pages · 101 KB · DETechnical specifications and performance data for the Meister DKM/TA flow meter with analog output.
BOTA BT702 Flow Totalizer User Manual
User Manual 18 pages · 1 MB · ZHUser manual for the BOTA BT702 flow totalizer covering installation, wiring, operation, and specifications.
Guanghua Instruments Liquid Crystal Flow Meter User Manual
User Manual 8 pages · 182 KB · ZHThe manual explains functions, keypad operation, display settings, parameter configuration, wiring, and battery replacement for the Guanghua liquid crystal…
Which document do I need?
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in flow transmitter manuals
What is the maximum operating pressure of the DKM/TA flow meter?
It can operate up to 250 bar (MS) or 300 bar (VA).
What output signals does the DKM/TA provide?
It provides a 4‑20 mA current loop and a 0‑10 V voltage output.
What input signal types does the BT702 support for flow measurement?
It accepts 0‑10 mA, 4‑20 mA, 0‑20 mA, 0‑5 V, 1‑5 V, pulse frequencies from 1 Hz to 8 kHz, and PNP/NPN switch signals.
Which communication interfaces are available on the BT702?
The instrument provides RS485 and RS232 communication ports.
How can I clear the class flow total?
Press and hold the k3 key for more than 5 seconds to reset the class flow counter.
From: Guanghua Instruments Liquid Crystal Flow Meter User Manual
How do I set the time and date?
Enter the time/date screen, press k2 to select a field, then use k2 to increment the value; use k1/k3 to move the cursor.
From: Guanghua Instruments Liquid Crystal Flow Meter User Manual
