transceiver Manuals

Key facts

Manuals

18

Models

1

Brands

2

Languages

EN

Last added

2026-09-29

transceiver models by brand

Featured transceiver manuals

AddOn TOM-10G-SFPP-SR1-AO SFP+ Transceiver Datasheet

Datasheet 7 pages · 2.9 MB · EN

The AddOn TOM-10G-SFPP-SR1-AO is a 10GBase‑LR SFP+ transceiver compatible with Tellabs® TOM-10G‑SFPP‑SR1. It is RoHS and Trade Agreements Act (TAA) compliant, offering hot‑pluggable operation and digital optical monitoring (DOM) for real‑time parameters.

Key features include an uncooled DFB transmitter, PIN receiver, duplex LC connector, and support for 10 km single‑mode fiber links at 1310 nm. The module meets SFF‑8432/8472 standards and provides robust ESD, EMI/EMC and laser safety compliance for data‑center, enterprise and mobile fronthaul applications.

Covers: Features and Applications · Regulatory Compliance · Electrical Characteristics · Optical Characteristics · Pin Descriptions · Mechanical Specifications

Latest transceiver manuals

• AddOn TOM-10G-SFPP-SR1-AO SFP+ Transceiver Datasheet

  Datasheet 7 pages · 2.9 MB · EN

  The AddOn TOM-10G-SFPP-SR1-AO SFP+ transceiver is a TAA‑compliant 10GBase‑LR module with detailed electrical, optical and mechanical specifications.

• PHILIPS 74LVT16543A transceiver

  The 74LVT16543A is a high-performance BiCMOS product designed for VCC operation at 3.3V. The device can be used as two 8-bit transceivers or one 16-bit transceiver. The 74LVT16543A contains two sets of eight D-type latches, with separate control pins for each set. Using data flow from A to B as an example, when the A-to-B Enable (nEAB) input and the A-to-B Latch Enable (nLEAB) input are Low, the A-to-B path is transparent.

• PHILIPS 74LVT543 transceiver

  The 74LVT543 is a high-performance BiCMOS product designed for VCC operation at 3.3V. This device contains two sets of D-type latches for temporary storage of data flowing in either direction. Separate Latch Enable (LEAB, LEBA) and Output Enable (OEAB, OEBA) inputs are provided for each register to permit independent control of data transfer in either direction. The outputs are guaranteed to sink 64mA.

• PHILIPS 74ALVT16245 transceiver

  The 74ALVT16245 is a high-performance BiCMOS product designed for VCC operation at 2.5V or 3.3V with I/O compatibility up to 5V.

• PHILIPS 74LVT640 transceiver

  The LVT640 is a high-performance BiCMOS product designed for VCC operation at 3.3V. This device is an octal transceiver featuring inverting 3-State bus compatible outputs in both send and receive directions. The control function implementation minimizes external timing requirements. The device features an Output Enable (OE) input for easy cascading and a Direction (DIR) input for direction control.

• PHILIPS 74LVT162245B transceiver

  The 74LVC16373A and 74LVCH16373A are 16-bit D-type transparent latches featuring separate D-type inputs with bus hold (74LVCH16373A only) for each latch and 3-state outputs for bus-oriented applications. One Latch Enable (LE) input and one Output Enable (OE) are provided for each octal. Inputs can be driven from either 3.3 V or 5 V devices. When disabled, up to 5.5 V can be applied to the outputs. These features allow the use of these devices in mixed 3.3 V and 5 V applications.

• PHILIPS 74LVT652 transceiver

  The LVT652 is a high-performance BiCMOS product designed for VCC operation at 3.3V. This device combines low static and dynamic power dissipation with high speed and high output drive. The 74LVT652 transceiver/register consists of bus transceiver circuits with 3-State outputs, D

• PHILIPS 74ALVT16652 transceiver

  The 74ALVT16652 is a high-performance BiCMOS product designed for VCC operation at 2.5V or 3.3V with I/O compatibility up to 5V. The device can be used as two 8-bit transceivers or one 16-bit transceiver.

• PHILIPS 74LVT646 transceiver

  The LVT640 is a high-performance BiCMOS product designed for VCC operation at 3.3V. This device is an octal transceiver featuring inverting 3-State bus compatible outputs in both send and receive directions. The control function implementation minimizes external timing requirements. The device features an Output Enable (OE) input for easy cascading and a Direction (DIR) input for direction control.

• PHILIPS 74ALVCH162245 transceiver

  The 74ALVCH162245 is a 16-bit transceiver featuring non-inverting 3-State bus compatible outputs in both send and receive directions. The 74ALVCH162245 features two output enable (nOE) inputs for easy cascading and two send/receive (nDIR) inputs for direction control. nOE controls the outputs so that the buses are effectively isolated. This device can be used as two 8-bit transceivers or one 16-bit transceiver.

• PHILIPS 74ALVCH16646 transceiver

  The 74ALVCH16646 consists of 16 non-inverting bus transceiver circuits with 3-State outputs, D-type flip-flops and control circuitry arranged for multiplexed transmission of data directly from the internal registers. Data on the

• PHILIPS 74ALVCH16601 transceiver

  The 74ALVCH16601 is an 18-bit universal transceiver featuring non-inverting 3-State bus compatible outputs in both send and receive directions. Data flow in each direction is controlled by output enable (OEAB and OEBA), latch enable (LEAB and LEBA), and clock (CPAB and CPBA) inputs. For A-to-B data flow, the device operates in the transparent mode when LEAB is High. When LEAB is Low, the A data is latched if CPAB is held at a High or Low logic level. If LEAB is Low, the A-bus data is stor

• PHILIPS 74ALVCH16500 transceiver

  The 74ALVCH16500 is a high-performance CMOS product. This device is an 18-bit universal transceiver featuring non-inverting 3-State bus compatible outputs in both send and receive directions. Data flow in each direction is controlled by output enable (OEAB and OEBA), latch enable (LEAB and LEBA), and clock (CPAB and CPBA) inputs. For A-to-B data flow, the device operates in the transparent mode when LEAB is High. When LEAB is Low, the A data is latched if CPAB is held at a High or Low log

• PHILIPS 74ABT2245 transceiver

  The 74HC2G86; 74HCT2G86 is a dual 2-input EXCLUSIVE-OR gate. Inputs include clamp diodes that enable the use of current limiting resistors to interface inputs to voltages in excess of VCC.

• PHILIPS 74ABT640 transceiver

  The 74ABT640 high-performance BiCMOS device combines low static and dynamic power dissipation with high speed and high output drive. The 74ABT640 device is an octal transceiver featuring inverting 3-State bus compatible outputs in both send and receive directions. The control function implementation minimizes external timing requirements. The device features an Output Enable (OE) input for easy cascading and a Direction (DIR) input for direction control.

Which document do I need?

Questions answered in transceiver manuals

transceiver manuals by brand
