Start here
OmniSite XR-50 Monitoring Device User Manual
The OmniSite XR‑50 is a 10‑channel monitoring device designed for water and wastewater utilities. It can be installed indoors or outdoors and operates from 120 VAC or solar panels (15‑20 VDC). The unit communicates over cellular networks using OmniSite’s WINGS™ system.
This guide covers safety warnings, wiring diagrams, installation steps, local display programming, web‑based configuration, and troubleshooting procedures. It also includes appendices with detailed programming instructions and software parameter settings.
OmniSite XR50 specifications
| Power Input | 12 VDC or 120 VAC |
|---|---|
| Cellular GSM Frequencies | 850/900/1800/1900 MHz |
| Operating Temperature | -20 °F to 150 °F |
| Dimensions | 8.9"H x 9.4"W x 3.5"D |
| Memory Capacity | 32 Mb – 1 Gb selectable |
| LCD Display | Backlit 2 × 16 |
| Universal Input Range | 12 VAC/VDC – 120 VAC/VDC |
All OmniSite XR50 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
How does the XR50 send alerts when an abnormal condition occurs?
It sends notifications by e‑mail, pager, or voice call to any location.
What are the power input options for the XR50?
The device can be powered by 12 VDC or 120 VAC.
How can I tell if the cellular signal is strong enough for installation?
Check the signal‑strength LED on the XR‑50; a green light indicates a good signal.
How can I enable low‑power mode for solar operation?
Use the local programming menu (Appendix A) to set the low‑power mode, which powers off the radio after one minute of inactivity.
