Beijing Niren Haian NWSF-1AT Temperature/Humidity Transmitter User Manual
This manual describes the NWSF-1AT temperature/humidity transmitter, a compact ABS‑housing sensor designed for indoor environmental monitoring. It lists the electrical requirements, measurement ranges, accuracies, and output signal details.
The document includes installation instructions, wiring diagrams, operating procedures, safety precautions, maintenance recommendations, storage conditions, and troubleshooting steps to ensure reliable performance in HVAC and industrial applications. This manual is written in Japanese.
NWSF-1AT specifications
| Supply voltage | DC24V (22V‑26V) |
|---|---|
| Humidity measurement range | 0 %RH – 100 %RH |
| Temperature measurement range | 0 °C – 50 °C |
| Humidity accuracy | ±0.5 %RH (10 %RH – 85 %RH) |
| Output signal | 4 – 20 mA current loop |
| Dimensions (W×H×D) | 90 mm × 65 mm × 20 mm |
Source: Beijing Niren Haian NWSF-1AT Temperature/Humidity Transmitter User Manual
All NWSF-1AT documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What supply voltage does the NWSF-1AT require?
It operates from a DC24 V supply, acceptable range 22 V to 26 V.
From: Beijing Niren Haian NWSF-1AT Temperature/Humidity Transmitter User Manual
What type of output signal does the transmitter provide?
The device outputs a 4 – 20 mA current loop signal.
From: Beijing Niren Haian NWSF-1AT Temperature/Humidity Transmitter User Manual
What power supply voltage does the NWSF-1AT require?
It requires a DC24 V supply, acceptable range 22 V to 26 V.
From: ColliHigh NWSF-1AT Temperature Humidity Transmitter User Manual
What is the temperature measurement range of the transmitter?
The device measures temperature from 0 °C up to 50 °C.
From: ColliHigh NWSF-1AT Temperature Humidity Transmitter User Manual
