Specification sheet for absolute and incremental optical encoders and compatible add‑on cards.
This document provides the specifications for absolute and incremental linear optical encoders used in servo products, as well as the compatible add‑on cards and modules required for communication with drivers. It includes part numbers, connector types, and version history.
The sheet is organized into sections for absolute encoders, incremental encoders, and add‑on cards/modules, followed by a document history table that records revisions and authorship. This manual is written in Chinese.
| Add‑on Card P01-STD-ADP-ABZ-1/3 | Single‑axis 10‑pin, Triple‑axis 10‑pin |
|---|---|
| Add‑on Card P01-MD4-ADP-STD-1.0 | Triple‑axis 6‑pin |
| Add‑on Card P06-MD4-ADP-ABZ-1.1 | Triple‑axis 10‑pin |
The document lists P01-STD-ADP-ABZ-1/3, P01-MD4-ADP-STD-1.0, P06-MD4-ADP-ABZ-1.1 and other modules such as S08‑SC‑ADAPTER.
The latest revision is V1.1 dated 2020‑10‑29, with an export date of 2023‑05‑10.
