Key facts
- Manuals
- 3
- Languages
- ZH
- Last added
- 2026-09-29
Featured Cognex manuals
Cognex DataMan 360 Series & MX-1000 Airport Baggage Handling Identification (ABH-ID) Solution
The ABH‑ID solution from Cognex uses image‑based DataMan 360 series readers and the MX‑1000 mobile terminal to reliably read damaged barcodes and QR codes on moving luggage. By capturing full‑color images of each tag, the system can diagnose read failures and provide visual evidence for training and quality control.
Key technologies include Hotbars® for reading severely damaged tags, Xpand™ optics that expand the field of view by more than 50 %, and a fast decoding engine that delivers sub‑second response times. The solution complies with the latest IATA 753 resolution, helping airlines reduce missed flights and improve passenger satisfaction. This manual is written in Chinese.
Covers: Solution Overview · Baggage Tag Reading Challenges · Cognex Technology Benefits · Comparison with Laser Scanners · DataMan 360 Series Features · MX‑1000 Mobile Terminal
Cognex DataMan 360 Quick Reference Guide
This guide presents essential safety precautions for the Class 2 laser device, including warnings not to look directly at the beam, not to attempt repair, and to keep the unit sealed for IP protection. It also outlines the product’s main components such as the laser sight, LED cluster, trigger button, and networking ports.
The document lists available accessories (various lenses, lens caps, filters, and illumination modules), specifies connection cable options, and details technical specifications like weight, operating temperature range, IP rating, and power requirements. Installation notes and regulatory compliance statements are also included. This manual is written in Chinese.
Covers: Safety Precautions · Product Overview · Accessories · Connection Cables · Dimensions · Field of View and Reading Distance
Latest Cognex manuals
Cognex DataMan 360 Series & MX-1000 Airport Baggage Handling Identification (ABH-ID) Solution
Product Leaflet 4 pages · 483 KB · ZHCognex presents an image‑based ABH‑ID solution that boosts baggage tag read rates, reduces manual handling and meets IATA standards.
Cognex DataMan 360 Quick Reference Guide
Quick Start Guide 24 pages · 3.5 MB · ZHThe Cognex DataMan 360 Quick Reference Guide provides safety warnings, product overview, accessories, cable connections, dimensions, field of view, and…
COGNEX Checker 200 series User Guide
Which document do I need?
Quick Start Guide
The shortest path to a working setup, usually only a few pages.
Questions answered in Cognex manuals
What is the MTBF of Cognex DataMan readers?
The DataMan readers have an average MTBF of 13 years.
From: Cognex DataMan 360 Series & MX-1000 Airport Baggage Handling Identification (ABH-ID) Solution
Can the ABH‑ID solution read QR codes?
Yes, the image‑based readers can read QR codes, whereas laser scanners cannot.
From: Cognex DataMan 360 Series & MX-1000 Airport Baggage Handling Identification (ABH-ID) Solution
