Featured 龙兴联 manuals
Longxing Lian PDC-Ⅱ Belt Scale Selection Manual
The PDC-Ⅱ high‑precision belt scale instrument from Longxing Lian integrates a latest system‑on‑chip (SOC) and Σ/Δ signal extraction technology to form an electronic belt scale. It supports an RS‑485 interface with MODBUS RTU protocol for fast data exchange with host computers or controllers, and can be networked with other MODBUS‑compatible devices.
Key specifications include a static weighing range of 0–150 kg, a maximum dynamic cumulative capacity of 4 300 000 t, and a peak instantaneous flow of 2400 kg/min. Belt speed is measured via encoder or gear speed sensors, while load is measured with an electronic strain‑gauge sensor. Communication settings use MODBUS RTU at 38400 baud. This manual is written in Chinese.
Covers: Selection Guide · Technical Description · Instrument Information · Ordering Information
Latest 龙兴联 manuals
Longxing Lian PDC-Ⅱ Belt Scale Selection Manual
Product Leaflet 2 pages · 174 KB · ZHThe Longxing Lian PDC-Ⅱ high‑precision belt scale selection manual provides specifications, interface details, and application information.
Xing Lian MODBUS to transfer PROFIBUS Module Reference Manual
Xing Lian RS232 to PROFIBUS module Reference Manual
Questions answered in 龙兴联 manuals
What communication interface does the PDC-Ⅱ belt scale use?
It uses an RS‑485 interface with the MODBUS RTU protocol.
What is the static weighing range of the PDC-Ⅱ?
The static weighing range is 0 to 150 kg.
