Guangzhou Riverstone technology CM12864-18SLYB graphics lattice liquid crystal display module Manual

User Manual 18 pages · 552 KB · ZH

The CML2864-18SLYB is a graphic dot‑matrix LCD module with a 128 × 64 dot display, built‑in negative‑voltage driver and selectable backlight colors. It operates from a +5 V supply and works in temperatures from –10 °C to +55 °C.

The manual describes the module’s mechanical dimensions, hardware block diagram, pin‑out, command set, timing parameters and includes an example interface to an 8031 microcontroller. This manual is written in Chinese.

Covers: Overview · Technical Parameters · Mechanical Dimensions · Hardware Block Diagram · External Interface · Command Description

Riverstone CM19264-4SLYB Graphics LCD Module Manual

User Manual 21 pages · 615 KB · ZH

The CM19264-4SLYB is a 192 × 64 dot matrix graphics LCD module with LED backlight. It operates from a +5 V supply and works in temperatures from –10 °C to +55 °C (storage –20 °C to +70 °C). The module uses a QB package and offers a viewing angle of 6°.

This manual describes the physical dimensions, external pin‑out, internal registers, XY and Z coordinate registers, timing diagrams, and example code for driving the display. It also lists electrical parameters and provides programming details for setting display data and control signals. This manual is written in Chinese.

Covers: Overview · Physical Dimensions · Module Functions · External Interface · Registers · XY Coordinate Register

Riverstone CM7401SLYB Graphics LCD Module Manual

User Manual 43 pages · 565 KB · ZH

This manual describes the Riverstone CM7401SLYB graphics LCD module, a 240 × 128 dot display driven by a T6963 controller. It includes hardware parameters, external connector pin‑outs, and power requirements.

The document also contains example code for interfacing the module with an 8031 microcontroller, as well as detailed electrical specifications such as supply voltages, temperature range, backlight type, and package information. This manual is written in Chinese.

Covers: Product Overview · Technical Specifications · Hardware Interface · External Connections · Electrical Parameters · Programming Example

Riverstone Technology CM12232-7SLYA Graphics LCD Module Manual

User Manual 19 pages · 52 KB · ZH

This manual describes the CM12232-7SLYA graphics LCD module produced by Riverstone Technology. It lists basic features, mechanical dimensions, electrical parameters, timing characteristics and the pinout for the 16‑pin package. The document also includes the command set used to control the display and examples of interfacing with an 8031 microcontroller.

Detailed tables give power supply ranges, voltage levels, current consumption, pixel resolution (122 × 32 dots) and backlight options. Instructions for resetting the display, enabling power‑save mode, and programming the display RAM are provided, along with sample code snippets. This manual is written in Chinese.

Covers: Basic Features · Mechanical Characteristics · Electrical Parameters · Timing Characteristics · Mechanical Dimensions · Pin Definitions
