Featured 固高(Shenzhen) manuals
Gold Control MTC300A/MTX300A/MTA300A/MTK300A/MT300A Thyristor Module Product Leaflet
Gold Control’s thyristor modules are designed for power‑electronics applications such as rectifiers, inverters, DC motor drives and high‑voltage power supplies. The modules feature international‑standard packaging, low on‑state voltage drop and high surge capability, and meet CE, ISO‑9001 and RoHS certifications.
The document lists key electrical parameters, mechanical dimensions (max 118 mm × 53 mm × 61 mm), recommended mounting procedures, thermal limits (‑40 °C to +125 °C junction temperature) and environmental requirements. Installation notes cover heat‑sink preparation, torque values for mounting screws, and recommended use of thermal paste. This manual is written in Chinese.
Covers: Features · Main Applications · Technical Specifications · Installation Guidelines · Usage Instructions · Performance Curves
GOLD CONTROL MDTC110A / MTDC110A / MTDX110A / MDTX110A Controllable Rectifier Hybrid Module Datasheet
The MDTC110A, MTDC110A, MTDX110A and MDTX110A modules are controllable rectifier hybrid devices offered by GOLD CONTROL. They feature international standard packaging, welded construction, low forward voltage drop, high surge capability, and compliance with RoHS. Typical applications include glass passivation, various rectifier power supplies, inverters, welding machines, DC charging supplies, and motor drives.
The document lists technical parameters such as rated currents, voltage ratings, thermal resistance, and mechanical dimensions, as well as installation torque values and environmental operating limits. Guidance on mounting, heat‑sink preparation, and recommended torque for M5 and M6 fasteners is also provided to ensure reliable operation. This manual is written in Chinese.
Covers: Features · Main Applications · Technical Parameters · Thermal Performance · Installation Torque · Usage Instructions
GOLD CONTROL MTG100A/MTY100A Thyristor Module Specification
The MTG100A and MTY100A are non‑isolated thyristor (silicon‑controlled rectifier) modules offered by GOLD CONTROL. They feature an international standard package, welded construction, low on‑state voltage drop (≤1.3 V), high surge capability (up to 12 ×), and are suitable for welding machines, inverters, motor soft‑start, and various DC power supplies.
The document lists key electrical ratings such as a blocking voltage of 800 V, a rated on‑state average current of 140 A, and a gate trigger current of 1.5 A. It also provides thermal data, physical dimensions (max 94 mm × 25 mm × 36 mm), and detailed installation instructions, including recommended torque values and surface preparation for optimal heat transfer. This manual is written in Chinese.
Covers: Features · Main Applications · Electrical Ratings · Thermal Performance · Physical Dimensions · Installation Guidelines
Latest 固高(Shenzhen) manuals
Gold Control MTC300A/MTX300A/MTA300A/MTK300A/MT300A Thyristor Module Product Leaflet
Product Leaflet 5 pages · 427 KB · ZHThe Gold Control thyristor module series (MTC300A, MTX300A, MTA300A, MTK300A, MT300A) data sheet provides specifications, installation and usage guidelines.
GOLD CONTROL MDTC110A / MTDC110A / MTDX110A / MDTX110A Controllable Rectifier Hybrid Module Datasheet
Datasheet 5 pages · 409 KB · ZHThe GOLD CONTROL MDTC110A/MTDC110A/MTDX110A/MDTX110A controllable rectifier hybrid module datasheet provides features, specifications, installation and…
GOLD CONTROL MTG100A/MTY100A Thyristor Module Specification
Datasheet 5 pages · 437 KB · ZHThe GOLD CONTROL MTG100A and MTY100A non‑isolated thyristor modules specification sheet provides features, electrical parameters, and installation guidelines.
Which document do I need?
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in 固高(Shenzhen) manuals
What is the recommended operating temperature range for the modules?
The thyristor modules are rated for a junction temperature of –40 °C to +125 °C (rectifier operation up to –40 °C to 150 °C).
From: Gold Control MTC300A/MTX300A/MTA300A/MTK300A/MT300A Thyristor Module Product Leaflet
How should the modules be mounted to a heat sink?
Mount the module with M5 or M6 screws and spring washers, applying a torque of 4–6 N·m, ensure the heat‑sink surface is smooth and clean, and apply a thin layer of thermal paste (~0.5 µm).
From: Gold Control MTC300A/MTX300A/MTA300A/MTK300A/MT300A Thyristor Module Product Leaflet
What is the operating temperature range of the module?
The module can operate from –40 °C to +125 °C junction temperature, and up to 150 °C for the rectifier mode.
What is the recommended installation torque for mounting the module?
Use a torque of 3 N·m for M5 screws and 4‑6 N·m for M6 screws when fastening the module to a heat sink.
What is the maximum blocking voltage of the MTG100A/MTY100A modules?
The modules can block up to 800 V.
From: GOLD CONTROL MTG100A/MTY100A Thyristor Module Specification
What is the recommended operating temperature range for these modules?
The semiconductor module is rated for a junction temperature from –40 °C to +125 °C.
From: GOLD CONTROL MTG100A/MTY100A Thyristor Module Specification
