Featured YL-72ZKG manuals
YL-72ZKG Temperature Controller User Manual
The YL‑72ZKG temperature controller is a self‑developed device that uses microcontroller software and an SSR‑DV solid‑state relay (or TRIAC) to continuously and smoothly adjust the load voltage from 0‑220 V. It features voltage‑feedback compensation for stable output, power‑off hold, and a programmable soft‑start function to protect heating elements.
The manual explains panel button functions, how to set and save soft‑start timing, wiring requirements, special precautions (such as matching phase lines and proper relay sizing), and provides single‑ and three‑phase wiring diagrams for installation. This manual is written in Chinese.
Covers: Overview · Panel Button Functions · Soft Start Function · Wiring and Usage Requirements · Special Precautions · Single‑Phase Wiring Diagram
Latest YL-72ZKG manuals
YL-72ZKG Temperature Controller User Manual
User Manual 2 pages · 265 KB · ZHUser manual for the YL‑72ZKG temperature controller, describing operation, wiring, soft‑start and safety precautions.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in YL-72ZKG manuals
What current rating should the SSR‑DV solid‑state relay have?
The relay’s current rating must be at least 1.5‑2.5 times the actual load current.
Can this controller be used with inductive loads such as induction furnaces?
No, the controller is not suitable for inductive loads like induction furnaces or step‑down transformers.
