Featured WWW.CAH.COM.HK manuals
CAH HQ-12 Full Range Loudspeaker System Manual
The CAH HQ-12 is a compact 2‑way passive loudspeaker system designed for corporate events, houses of worship, live music clubs, small auditoriums and meeting rooms. It features a 12" low‑frequency woofer and a 1.75" high‑frequency compression driver with a 60° × 60° coverage pattern, Neutrik Speakon connectors, and options for flying or floor‑stand mounting.
The manual lists detailed technical specifications such as a 50 Hz‑20 kHz frequency range, 97 dB sensitivity, 122 dB maximum SPL, 300 W power handling, 8 Ω nominal impedance, and dimensions of 618 mm × 326 mm × 418 mm. It also includes warranty terms that cover one year from the original purchase date.
Covers: Applications · Features · Specifications · Warranty
CAH HQ-15 Full Range Loudspeaker System Manual
The HQ-15 Full Range Loudspeaker System is designed for corporate events, houses of worship, live music clubs, small auditoriums and meeting rooms. It features a 15" low‑frequency driver and a 2" high‑frequency compression driver with 60° × 60° constant‑directivity coverage, and can be mounted on a floor stand or flown.
Key specifications include a frequency range of 45 – 19 kHz, 99 dB sensitivity, 124 dB maximum SPL, 350 W power handling, 8 Ω nominal impedance, and dual Neutrik Speakon inputs. The unit measures 718 mm high, 412 mm wide (front), 219 mm wide (rear), 500 mm deep and weighs about 40 kg. It comes with a black painted finish and a one‑year limited warranty.
Covers: Applications · Features · Specifications · Limited Warranty
Latest WWW.CAH.COM.HK manuals
CAH HQ-12 Full Range Loudspeaker System Manual
Product Leaflet 2 pages · 839 KB · ENThe CAH HQ-12 manual provides specifications, features, and warranty information for the compact 2‑way full‑range loudspeaker system.
CAH HQ-15 Full Range Loudspeaker System Manual
User Manual 2 pages · 838 KB · ENThe CAH HQ-15 is a compact 2‑way full‑range loudspeaker with a 15" woofer, 2" compression driver, high sensitivity and Neutrik Speakon connections.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in WWW.CAH.COM.HK manuals
What type of input connectors does the HQ-15 use?
It uses two Neutrik Speakon connectors for input.
How long is the warranty period for the HQ-15?
CAH provides a one‑year limited warranty from the date of purchase.
