Featured WIKA manuals
WIKA CPG 8000 Pressure Indicator Data Sheet
The CPG 8000 is a modular high‑precision pressure indicator that can integrate up to four pressure sensors and an optional barometric reference. It offers a high‑resolution colour graphics display, programmable relay outputs, a data logger, and functions such as Min, Max, Hold, Zero, Average, and pressure rate.
The instrument provides RS‑232 and IEEE‑488.2 communication interfaces, optional software EasyCal for calibration, and can be configured for desktop or plug‑in case versions. It is suited for national institutes, R&D labs, industry, and calibration service companies.
Covers: Applications · Special features · Description · Functionality · Software · Input socket and interfaces
WIKA TR200 Resistance Temperature Sensor Manual
The TR200 is an integrated resistance temperature sensor (RTD) designed for use in industrial, chemical, food, and energy applications. It offers a wide temperature range and ATEX‑certified intrinsic safety for hazardous environments.
The manual provides details on sensor replacement, mounting options, connection types (1 × Pt100 or 2 × Pt100), and the required 4‑20 mA or HART transmitters. It also includes tables of accuracy, dimensions, and recommended installation procedures. This manual is written in Chinese.
Covers: Features · Technical specifications · Installation and mounting · Electrical connection options · ATEX safety certification · Sensor replacement
Latest WIKA manuals
WIKA CPG 8000 Pressure Indicator Data Sheet
Datasheet 6 pages · 461 KB · ENThe WIKA CPG 8000 data sheet details its modular high‑precision pressure indicator features, specifications, and interfaces.
WIKA TR200 Resistance Temperature Sensor Manual
User Manual 8 pages · 334 KB · ZHUser manual for the WIKA TR200 resistance temperature sensor covering specifications, installation and connection options.
Which document do I need?
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in WIKA manuals
How many sensors can be integrated into the CPG 8000?
The CPG 8000 can integrate up to four high‑precision pressure sensors.
What is the maximum pressure range of the CPG 8000?
It covers pressure ranges from 0 … 0.1 bar up to 0 … 2500 bar, depending on the sensor used.
Is the TR200 ATEX certified?
Yes, the TR200 is an intrinsically safe device certified for ATEX applications.
