Featured WALL manuals

Sony Wall Mounting Installation Guide

Installation Guide 2 pages · 232 KB · ZH

The guide explains how to prepare a suitable wall location, mark drilling points using the provided template, and drill two 6 mm diameter holes. After drilling, dowels and screws are inserted, leaving the screws 5 mm protruding from the wall, allowing the main unit and speakers to be hung securely.

Safety precautions stress that only qualified personnel should perform the installation, checking for hidden wiring or piping, selecting appropriate tools, and following the detailed steps for attaching and detaching the stand. This manual is written in Chinese.

Covers: Wall mounting instructions · Preparation · Drilling holes · Securing dowels and screws · Detaching the stand · Safety precautions

Latest WALL manuals

• WALL DMW Ultra Wide Series Single Dual Output 15 Watt DC/DC Converter 4:1 Ultra Wide Input Voltage Range

  DMW Ultra Wide Series is a 15-watt DC/DC converter from Wall Industries, Inc. that has a 4:1 ultra wide input voltage range, up to 86% efficiency, MTBF>700,000 hours, and is UL1950 safety approved.

• WALL SPW48S24-100 100W DC-DC Converter 18-75 Vdc Input 24Vdc Output at 4.16A Half-Brick Package Manual

  This document describes the features and characteristics of the SPW48S24-100 100W DC-DC converter, including high efficiency, fast transient response, output trim, remote ON/OFF, etc.

• WALL SPW48S24-100 100W DC-DC Converter 18-75 Vdc Input 24Vdc Output at 4.16A Half-Brick Package Guide

  The SPW48S24-100 is a 100W DC-DC converter with an input voltage range of 18-75Vdc and an output voltage of 24Vdc at 4.16A.

• Sony Wall Mounting Installation Guide

  Installation Guide 2 pages · 232 KB · ZH

  Step‑by‑step instructions for safely wall‑mounting the Sony speaker system, including drilling, fastening and safety notes.
