Featured Victaulic manuals
Victaulic W730 Series Vic-Strainer Filter Installation Manual
This manual describes the Victaulic W730 series Vic‑Strainer filter, a lightweight, straight‑through flow filter with low pressure drop. It details the two Victaulic couplings used for installation and the maximum rated pressure of 300 psi (2065 kPa).
The document includes dimensional tables, performance data, material specifications, sealing gasket options, and warranty information, along with references to additional installation resources on the Victaulic website. This manual is written in Chinese.
Covers: Product Overview · Size and Dimension Specifications · Pressure Rating · Mesh and Filter Media · Performance Data (Flow & CV) · Materials and Construction
Victaulic 707 Butterfly Valve Installation and Gear Mechanism Replacement Guide
The document details the proper installation of the 707 series butterfly valve, including important safety warnings such as wearing protective eyewear, a hard hat, and foot protection, and depressurizing and draining the pipe system before work. It also lists the valve’s pressure rating (300 psi/2065 kPa), UL and FM certifications, EPDM valve‑seat material, and required pipe type (grooved IPS carbon‑steel).
Installation steps cover positioning the valve in the closed position, using at least one rigid Victaulic joint, wiring the two DPDT monitoring switches, and the procedure for removing and reinstalling the gear operation mechanism with correct orientation and fasteners. The guide also provides wiring diagrams and color codes for the switches and grounding. This manual is written in Chinese.
Covers: Dimensions · Important Installation Information · Warnings · Switches and Wiring · Gear Mechanism Replacement · Installation Method
Latest Victaulic manuals
Victaulic W730 Series Vic-Strainer Filter Installation Manual
Installation Guide 8 pages · 884 KB · ZHThe Victaulic W730 series Vic‑Strainer filter installation manual provides specifications, pressure ratings, and assembly instructions.
Victaulic 707 Butterfly Valve Installation and Gear Mechanism Replacement Guide
Installation Guide 2 pages · 1014 KB · ZHThis guide provides installation instructions, safety warnings, and gear mechanism replacement steps for the Victaulic 707 series butterfly valve.
Which document do I need?
Installation Guide
Mounting, wiring and first power-up. Read it before the hardware goes in.
Questions answered in Victaulic manuals
What is the maximum pressure rating of the W730 filter?
The filter is rated for a maximum pressure of 300 psi (2065 kPa).
From: Victaulic W730 Series Vic-Strainer Filter Installation Manual
What material is the filter basket made of?
Both the basket frame and the filter mesh are made of 304 stainless steel.
From: Victaulic W730 Series Vic-Strainer Filter Installation Manual
Which type of pipe can be used with the 707 series butterfly valve?
Only grooved IPS carbon‑steel pipe is approved; plain‑end IPS pipe or grooved ductile‑iron pipe must not be used.
From: Victaulic 707 Butterfly Valve Installation and Gear Mechanism Replacement Guide
What is the maximum working pressure of the 707 series butterfly valve?
The valve is rated for a maximum working pressure of 300 psi (2065 kPa).
From: Victaulic 707 Butterfly Valve Installation and Gear Mechanism Replacement Guide
