UE Manuals

Key facts

Manuals

17

Models

5

Languages

ZH · EN

Last added

2012-02-10

UE models by category

Featured UE manuals

UE 100 series temperature Switch Number B100 C100 E100 F100 installation maintenance Manual

Installation Guide 3 pages · 158 KB · ZH

This manual provides step‑by‑step instructions for installing UE 100 series temperature switches, including safety warnings, required tools, and wiring guidelines. It covers the B100, C100, E100 and F100 models and explains how to avoid exceeding the maximum temperature rating.

The guide also describes how to calibrate and adjust the set‑point temperature, how to perform periodic inspections, and what precautions must be taken in humid or high‑vibration environments to ensure reliable operation. This manual is written in Chinese.

Covers: Overview · Installation · Tools · Adjustment and Calibration · Precautions

UE UEL050 Single Output Switch Power Supply User Manual

User Manual 5 pages · 266 KB · ZH

The UE UEL050 series provides a 50 W single‑output switch‑mode power supply suitable for LED lighting and mobile applications. It accepts a universal AC input range up to 305 VAC, offers short‑circuit and overload protection, and features active power‑factor correction with a PF greater than 0.9.

The unit is rated IP67 for dust and water resistance, can be installed indoors or outdoors, and includes options for constant‑current (CC) or constant‑voltage (CV) LED driving. Output voltage and current can be set via an external cable or an internal potentiometer, and the manual includes EMI mitigation guidelines and waterproof connector details. This manual is written in Chinese.

Covers: Features · Electrical Specifications · Performance Curves · LED Driving Modes · EMI Mitigation · Waterproof Connectors

UE UEL130 Series Single-Phase Output Switch Power Supply Specification Sheet

Datasheet 5 pages · 901 KB · ZH

The UEL130 is a 130 W single‑phase switch power supply offering multiple output voltage options (24 V, 36 V, 42 V, 48 V, 52 V, 54 V) and corresponding maximum output currents up to 5.4 A. It operates from 230 VAC or 115 VAC input, provides high efficiency (up to 93 %) and a power factor of 0.95‑0.98.

The unit complies with numerous safety and EMC standards (EN61347‑1, UL60950‑1, EN55022 Class B, etc.), measures 216 mm × 70 mm × 40 mm (L × W × H), weighs about 1.2 kg, and has an MTBF of 207.9 khrs. Output ripple is limited to 250‑400 mV p‑p with voltage regulation of ±0.5 %. This manual is written in Chinese.

Covers: Electrical Parameters · Output Voltage Options · Maximum Output Current · Efficiency and Power Factor · Dimensions and Weight · Certifications

Philips UEL039-SXXXV/CYYY-Z1 LED Lamp Datasheet

Datasheet 5 pages · 284 KB · ZH

The Philips UEL039‑SXXXV/CYYY‑Z1 is a 39 W LED lamp available in four output voltage versions (24 V, 36 V, 42 V, 48 V). It operates from either 230 VAC or 115 VAC mains, offering high efficiency (up to 85 %) and a power factor of 0.9 / 0.95 depending on the input voltage.

The lamp is rated IP67 for dust and water protection, complies with multiple international standards (UL, EN61347, GB7000.1, etc.), and measures 140 × 40 × 36 mm with a weight of 0.9 kg. Detailed electrical parameters, component values, and certification information are provided in the datasheet. This manual is written in Chinese.

Covers: Electrical Ratings · Input Voltage · Power Factor · Efficiency · Output Voltage Options · IP Rating

Latest UE manuals

• UE 100 series temperature Switch Number B100 C100 E100 F100 installation maintenance Manual

  Installation Guide 3 pages · 158 KB · ZH

  Installation and maintenance guide for UE 100 series temperature switches (models B100, C100, E100, F100).

• UE UEL200 series Single Road output Switch power supply Manual

• UE UEL080 series Single Road output Switch power supply Manual

• UE UEL 160 series Single Road output Switch power supply Manual

• UE UEL050 Single Output Switch Power Supply User Manual

  User Manual 5 pages · 266 KB · ZH

  The UE UEL050 series is a 50 W single‑output switch‑mode power supply with IP67 rating, short‑circuit and overload protection, and adjustable output voltage.

• UE UEL130 Series Single-Phase Output Switch Power Supply Specification Sheet

  Datasheet 5 pages · 901 KB · ZH

  The UE UEL130 series is a 130 W single‑phase switch power supply with detailed electrical specs, dimensions and certifications.

• UE UEL220 series Single Road output Switch power supply Manual

• UE UEL100 series Single Road output Switch power supply Manual

• UE UEL160-SXXXV/CYYY-A1 series series Single Road output Switch power supply Manual

• UE UEL160-SXXXV/CYYY-A1 series Single Road output Switch power supply Manual

• Philips UEL039-SXXXV/CYYY-Z1 LED Lamp Datasheet

  Datasheet 5 pages · 284 KB · ZH

  Technical specifications for the Philips UEL039-SXXXV/CYYY-Z1 39W LED lamp, covering electrical ratings, dimensions, and certifications.

• UE UEL040-SXXXV/CYYY-Z1 series Single Road output Switch power supply Manual

  Datasheet 5 pages · 270 KB · EN

  The UE UEL040 40W single‑channel LED driver datasheet provides electrical specifications, performance curves, safety standards, and installation guidelines.

• UE UEL060/050-SXXXV/CYYY-Z1 series Single Road output Switch power supply Manual

  User Manual 5 pages · 336 KB · ZH

  The UE UEL060/050 single‑channel switch power supply manual provides specifications, wiring, safety, and installation guidelines.

• UE UEL070-SXXXV/CYYY-Z1 series Single Road output Switch power supply Manual

• UE UEL060-SXXXV/CYYY-Z1 series Single Road output Switch power supply Manual(1)

Which document do I need?

Questions answered in UE manuals
