Featured Thinkcore manuals
Moxa ThinkCore W345 User Manual
This manual describes the ThinkCore W345 industrial gateway, which integrates a MOXA ART ARM9 32‑bit RISC CPU, 64 MB DRAM, 16 MB flash, and built‑in GSM/GPRS communication modules. It runs a Linux 2.6 kernel and supports various network services such as TCP/UDP, HTTP, SSH, and VPN.
The document lists the mechanical dimensions (150 × 100 × 38 mm, 400 g), environmental ratings (‑10 °C to 60 °C operation, 5 G shock, 15 kV ESD), power input (12‑48 VDC), and all available interfaces, including RS‑232/422/485 three‑in‑one, 10/100 Mbps Ethernet, two USB 2.0 hosts, an SD card slot, and an RJ45 connector. Certification information (CE, TUV, UL, RoHS) and warranty details are also included. This manual is written in Chinese.
Covers: Hardware Overview · CPU and Memory · Communication Interfaces · Mechanical Dimensions · Electrical Characteristics · Environmental Ratings
Moxa W341 Industrial Computer User Manual
This manual describes the ThinkCore W341 industrial computer, which is built around a MOXA ART ARM9 32‑bit RISC CPU running at 192 MHz and includes 64 MB of DRAM and 16 MB of flash storage. It supports Ethernet, RS‑232/422/485, USB, SD card expansion, and dual‑band 802.11a/b/g Wi‑Fi, making it suitable for data collection, monitoring, and remote control applications.
The document also covers power requirements (12‑48 VDC input, 600 mA consumption), mechanical dimensions (150 × 100 × 38 mm, 390 g), environmental ratings, and the pre‑installed Linux 2.6 operating system with networking and security services. Installation options include wall‑mounting or DIN‑rail mounting, and detailed wiring diagrams for serial and Ethernet interfaces are provided. This manual is written in Chinese.
Covers: Hardware Specifications · CPU and Memory · Interfaces · Wireless (WLAN) · Power and Environmental · Dimensions and Mounting
Latest Thinkcore manuals
Moxa ThinkCore W345 User Manual
User Manual 3 pages · 920 KB · ZHThe Moxa ThinkCore W345 User Manual provides hardware specifications, interface details, and setup instructions for the GSM/GPRS‑enabled industrial gateway.
Moxa W341 Industrial Computer User Manual
User Manual 3 pages · 918 KB · ZHThe Moxa W341 industrial computer manual provides hardware specifications, installation instructions, and configuration details for the ThinkCore W341 device.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in Thinkcore manuals
What CPU does the ThinkCore W345 use?
It uses a MOXA ART ARM9 32‑bit RISC CPU running at 192 MHz.
What are the power input requirements?
The device operates from a 12 V to 48 V DC power supply.
What processor does the ThinkCore W341 use?
It uses a MOXA ART ARM9 32‑bit RISC CPU running at 192 MHz.
How many USB ports are available on the W341?
The device provides two USB 2.0 host ports.
