Featured Tekronix manuals
Tektronix DPO4000/MSO4000 Series Wave Inspector Control Manual
The DPO4000 and MSO4000 series are digital (mixed‑signal) oscilloscopes that combine high‑performance bandwidth, fast sample rates and extensive serial‑protocol analysis. The series offers a 10.4‑inch XGA color display, USB and CompactFlash for easy data transfer, and built‑in Wave Inspector for advanced waveform zoom, pan and analysis.
The manual describes how to use the front‑panel controls, configure serial interfaces (SPI, I²C, RS‑232, CAN), and connect the instrument via USB, LAN or GPIB adapters. It also lists technical specifications, warranty information and optional accessories such as TekVPI probe adapters. This manual is written in Chinese.
Covers: Main Features · Wave Inspector Control Function · Mixed‑Signal Design and Analysis · Serial Trigger and Analysis · Waveform Mathematics · Specifications
Tektronix TDS1000/TDS2000 Series Digital Storage Oscilloscope User Manual
The Tektronix TDS1000/TDS2000 series are compact, portable digital storage oscilloscopes offering up to 200 MHz bandwidth and 2 GS/s sampling. They provide a range of trigger options, automatic measurement functions, and FFT analysis for signal diagnostics.
The manual describes hardware specifications, interface options such as GPIB, RS‑232 and CompactFlash storage, as well as software tools like OpenChoice for data transfer and report generation. Warranty, technical support, and accessory information are also included. This manual is written in Chinese.
Covers: Features and Advantages · Capture Modes · Trigger System · Measurement System · Interfaces · Non‑volatile Storage
Latest Tekronix manuals
Tektronix DPO4000/MSO4000 Series Wave Inspector Control Manual
User Manual 11 pages · 2.2 MB · ZHThis manual explains the features, Wave Inspector controls, serial analysis and connectivity of Tektronix DPO4000 and MSO4000 series oscilloscopes.
Tekronix WVR5000/4000 Manual
Tekronix WFM90D/WFM91D hand-held waveform monitor Manual
Tektronix TDS1000/TDS2000 Series Digital Storage Oscilloscope User Manual
User Manual 8 pages · 917 KB · ZHUser manual for Tektronix TDS1000 and TDS2000 series digital storage oscilloscopes, covering features, operation, and specifications.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in Tekronix manuals
What is the Wave Inspector function?
Wave Inspector provides advanced waveform analysis, allowing rapid zoom, pan and detailed inspection of captured data.
From: Tektronix DPO4000/MSO4000 Series Wave Inspector Control Manual
How many digital channels are available on the MSO4000 series?
The MSO4000 series includes 16 integrated digital channels.
From: Tektronix DPO4000/MSO4000 Series Wave Inspector Control Manual
What is the maximum bandwidth of the TDS2000 series?
The TDS2000 series provides up to 200 MHz bandwidth.
From: Tektronix TDS1000/TDS2000 Series Digital Storage Oscilloscope User Manual
