Featured TDR manuals
TDR Series Power Supply Transformer Manual
This manual covers the TDR series power supply transformers, which are used in a variety of industrial and automation applications. It lists the available models, their rated capacities, and typical usage environments.
The document details normal operating conditions, environmental limits, physical dimensions, and installation requirements, including cable length limits and humidity tolerances. Key performance parameters such as frequency, input voltage, and output ratings are also provided. This manual is written in Chinese.
Covers: Purpose and Applications · Model and Ratings · Operating Conditions and Installation Requirements · Main Parameters and Performance · Features · Physical Dimensions and Installation Size
Latest TDR manuals
TDR Series Power Supply Transformer Manual
User Manual 2 pages · 783 KB · ZHThe TDR series power supply transformer manual provides specifications, operating conditions, dimensions, and installation guidelines for models TDR-10 to…
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in TDR manuals
What is the maximum allowed cable length for installation?
The transformer can be installed with a cable length up to 2000 m.
What are the dimensions of the TDR-160 model?
The TDR-160 measures 140 mm × 115 mm × 63 mm (B×D×E).
