Featured Syntec manuals
SYNTEC SMD-30/30/30/30-XS Servo Drive Hardware Manual
This hardware manual covers the SYNTEC SMD-30/30/30/30-XS servo drive, presenting its hardware specifications, dimensions, and safety precautions. It includes detailed wiring diagrams, connector definitions, and guidance for selecting regenerative resistors.
Key sections include the appearance and dimension details, power and control specifications, encoder interface options, and step‑by‑step installation and wiring instructions to ensure correct setup and safe operation. This manual is written in Chinese.
Covers: Preface · Application · Hardware Specification · Transportation and Installation · Wiring and Signal · Regenerator Selection
Syntec EZ Series Controller Installation Guide
The manual describes how to connect the Syntec EZ Series controller to a machine tool, covering power wiring, peripheral devices, spindle and servo units, and network configuration. It includes detailed electrical and structural specifications, installation dimensions, and interface definitions.
Chapters guide the user through hardware installation, power connection, I/O and peripheral wiring, emergency‑stop handling, Ethernet communication, and network settings for Windows and TCP/IP environments. Reference tables list related manuals and provide URLs for additional technical support. This manual is written in Chinese.
Covers: Product Introduction · Installation Dimensions and Interface Definition · Installation Conditions · Power Connection · Peripheral Device Connection · Spindle Unit Connection
Latest Syntec manuals
SYNTEC SMD-30/30/30/30-XS Servo Drive Hardware Manual
User Manual 51 pages · 695 KB · ZHThe SYNTEC SMD-30/30/30/30-XS servo drive hardware manual provides specifications, installation, wiring and signal information.
Syntec EZ Series Controller Installation Guide
Installation Guide 70 pages · 3.4 MB · ZHThis Syntec EZ Series controller installation guide provides wiring, hardware connection, and network setup instructions for EZ series CNC controllers.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Installation Guide
Mounting, wiring and first power-up. Read it before the hardware goes in.
Questions answered in Syntec manuals
What voltage does the SMD-30/30/30/30-XS servo drive require?
It requires a 3‑phase supply of 200 V to 230 V at 50 Hz or 60 Hz.
How many digital input ports are available on the drive?
The drive provides four digital input ports that can be configured for different functions.
How do I set the controller's IP address?
Enter the controller's network settings and set the address to 192.168.0.1, ensuring the last octet differs from the PC and is within 1‑254.
What is the default workgroup name for the controller?
The default workgroup name is SYNTEC.
