Featured Solid manuals
Solid UFD2100 Ultrasound Flaw Detection Instrument Manual
The Solid UFD2100 is a portable ultrasound flaw detection instrument designed for inspecting internal defects in metal materials and other applications such as welding, petrochemical pipelines, nuclear industry, pressure vessels, aerospace components, and castings. It offers a large 10 000 mm measurement range and adjustable pulse repetition frequency for flexible inspection needs.
Key features include a 10‑bit high‑precision AD sampler, industrial‑grade wide‑temperature TFT color LCD with 60 Hz refresh, up to 12 hours of continuous battery operation, and extensive data storage for multiple inspection channels and waveforms. The device supports various scanning modes, customizable GUI themes, and automatic sound‑speed calibration. This manual is written in Chinese.
Covers: Performance Specifications · Measurement Range · ADC Resolution · Display and Refresh Rate · Battery and Operating Time · Environmental Conditions
Latest Solid manuals
Solid State Sensors SS400 Series DATA SHEET
The Solid State Sensors SS400 Series digital position sensors have features such as a 3.8-30 VDC supply voltage, digital current sinking output, 3 pin in-line PCB terminals, and a quad-Hall design that virtually eliminates mechanical stress effects. They also have temperature compensated magnetics and customizable operate/release points. The sensors support bipolar, unipolar, and latching magnetics. They have a high output current capability of up to -50 mA and operate/release points symmetrically around zero gauss (bipolar/latch). The operating temperature range is -40 to +150°C (-40 to +302°F). The package material is Plaskon 3300H. A surface mount version is also available: SS400-S (with cut and formed leads).
Solid UFD2100 Ultrasound Flaw Detection Instrument Manual
User Manual 2 pages · 211 KB · ZHThe Solid UFD2100 manual provides operating instructions, specifications, and safety information for the portable ultrasound flaw detection instrument.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in Solid manuals
What is the measurement range of the Solid UFD2100?
The instrument can measure up to 10 000 mm.
From: Solid UFD2100 Ultrasound Flaw Detection Instrument Manual
How long can the UFD2100 operate continuously on its battery?
It can run for more than 12 hours on a full charge.
From: Solid UFD2100 Ultrasound Flaw Detection Instrument Manual
