Featured Shark100高精度多功能电力仪表 manuals
EIG Shark100 Electric Power Meter User Manual
The Shark100 is a high‑accuracy, multi‑function electric power meter designed for utility, commercial, sub‑station and industrial metering. It offers 0.2S class energy and demand measurement, optional VSWITCH technology, and a range of communication ports.
This manual covers the main features, installation methods (ANSI/DIN panel holes), wiring options, communication interfaces (RS485 Modbus/DNP3.0, 10/100 M Ethernet, IrDA), technical specifications, dimensions, environmental limits, and certification information. This manual is written in Chinese.
Covers: Main Features · Application Areas · VSWITCH Technology · Communication Interfaces · Installation Guidelines · Technical Specifications
EIG Shark100 Multi-Function Electric Instrument Table User Manual
The Shark100 is a high‑accuracy, multi‑function electric instrument designed for power metering in grid, commercial, sub‑station and industrial applications. It offers 0.2S class energy and demand measurement, voltage, current, power, harmonic monitoring and optional communication ports.
The manual provides details on V‑Switch technology, selectable communication options (RS485 Modbus/DNP3.0, Ethernet, IrDA, KYZ pulse), installation dimensions for ANSI or DIN panels, electrical specifications, and environmental ratings. This manual is written in Chinese.
Covers: 主要特点 · 技术规范 · 通讯接口 · 安装方式 · 电压输入 · 电流输入
Latest Shark100高精度多功能电力仪表 manuals
EIG Shark100 Electric Power Meter User Manual
User Manual 4 pages · 3.8 MB · ZHThe EIG Shark100 electric power meter manual provides specifications, installation instructions, communication options, and operation details.
EIG Shark100 Multi-Function Electric Instrument Table User Manual
User Manual 4 pages · 3.8 MB · ZHThe Shark100 manual describes its high‑accuracy multi‑function measurement features, installation options, and communication interfaces.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in Shark100高精度多功能电力仪表 manuals
How can the Shark100 be installed in a panel?
It can be mounted in a 102 mm round hole or a 92 mm IEC DIN square hole, complying with ANSI and DIN standard opening sizes.
How can the Shark100 be mounted in a panel?
It can be installed in a standard 102 mm round ANSI hole or a 92 mm IEC/DIN square hole, fitting both new and retrofit panels.
From: EIG Shark100 Multi-Function Electric Instrument Table User Manual
What is the accuracy class of the Shark100 energy measurement?
The device meets the 0.2S class (IEC 687) accuracy for energy and demand metering.
From: EIG Shark100 Multi-Function Electric Instrument Table User Manual
