Key facts
- Manuals
- 3
- Languages
- ZH
- Last added
- 2012-03-13
Featured SEMEM manuals
SEMEM DFK Electric Valve Controller User Manual
This manual describes the DFK electric valve controller, a low‑voltage DC control device for opening and closing electric valves. It outlines key features such as accurate opening‑degree indication, compact housing, and multiple status indicator lights.
The document includes technical data, front and rear panel component descriptions, operating principles, and step‑by‑step installation and adjustment procedures, as well as debugging instructions and safety precautions. This manual is written in Chinese.
Covers: Overview · Technical Data · Dimensions and Installation · Front Panel Components · Rear Panel Components · Operation Principle
SEMEM DFK-1G/-2G Electric Valve Controller User Manual
The DFK‑1G/-2G electric valve controller is a wall‑mounted control box designed to open and close electric valve actuators. It uses low‑voltage DC control, offers clear status LEDs, and includes safety alarms for overload or motor overheating.
The manual covers front‑panel functions, internal wiring, working principles, and step‑by‑step installation and adjustment procedures, allowing users to set up local or remote control, adjust the opening display, and verify correct operation. This manual is written in Chinese.
Covers: Overview · Features · Technical Data · Front Panel Description · Internal Components · Working Principle
SEMEM DFK-5, DFK-6, DFK-7, DFK-8 Valve Controller User Manual
The DFK valve controller is designed to control electric valve actuators for opening and closing, supporting both local and remote operation with optional 4‑20 mA valve‑position output. It is used in industries such as petroleum, chemical, hydro‑electric, coal and metallurgy.\n\nThe manual covers technical specifications, wiring diagrams, panel layout, operation procedures and safety instructions for the DFK‑5, DFK‑6, DFK‑7 and DFK‑8 models, including installation, adjustment of the opening indicator and troubleshooting. This manual is written in Chinese.
Covers: Overview · Technical Parameters · Working Principle · Panel Operation · Usage Instructions
Latest SEMEM manuals
SEMEM DFK Electric Valve Controller User Manual
User Manual 4 pages · 148 KB · ZHThe SEMEM DFK electric valve controller user manual provides overview, specifications, installation, adjustment, and operation instructions.
SEMEM DFK-1G/-2G Electric Valve Controller User Manual
User Manual 5 pages · 163 KB · ZHThe SEMEM DFK-1G/-2G electric valve controller manual provides operation, installation, and troubleshooting instructions.
SEMEM DFK-5, DFK-6, DFK-7, DFK-8 Valve Controller User Manual
User Manual 5 pages · 404 KB · ZHThe SEMEM DFK valve controller manual provides overview, technical parameters, wiring, panel operation and usage instructions for models DFK-5 to DFK-8.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in SEMEM manuals
What is the working voltage of the DFK controller?
The controller operates at 220 V, 50 Hz.
How can the valve opening display be set to 100%?
When the valve is fully open, adjust the potentiometer so the opening‑degree indicator shows 100%.
How do I switch between local and remote control modes?
Use the 现场/远控旋钮 to select the working mode; the local light turns on for local control and the remote light turns on for remote control.
From: SEMEM DFK-1G/-2G Electric Valve Controller User Manual
What do the indicator lights on the front panel mean?
The green valve‑open light flashes while opening and stays solid when fully open; the yellow valve‑close light behaves similarly for closing; the red accident light indicates overload or torque fault.
From: SEMEM DFK-1G/-2G Electric Valve Controller User Manual
What is the valve‑position output signal of the DFK controller?
The controller provides a 4‑20 mA output signal representing valve position.
From: SEMEM DFK-5, DFK-6, DFK-7, DFK-8 Valve Controller User Manual
How do you switch the controller between manual and automatic mode?
Use the toggle switch: the Manual (Nanual) position allows self‑locked operation, while the Automatic position is controlled by an external device without self‑lock.
From: SEMEM DFK-5, DFK-6, DFK-7, DFK-8 Valve Controller User Manual
