SEATECH models by category
Featured SEATECH manuals
SEATECH S104/sx-340 PC104 System Board User Manual
The SEATECH S104/sx-340 is a PC/104 compatible system board based on the low‑power ALI Me117C CPU and 4 MB DRAM. It supports both CRT and LCD displays, multiple serial ports, IDE storage, Ethernet, and a variety of I/O signals, making it suitable for embedded industrial applications.
The manual covers the board’s features, mechanical dimensions, pin‑out tables, BIOS settings, power‑supply requirements, installation steps, interface specifications, and a troubleshooting section that lists common faults and their remedies. This manual is written in Chinese.
Covers: Overview · Features · Technical Specifications · Installation and Configuration · Interface Details · BIOS Settings
SEATECH PC104/DX-440F Embedded Industry Motherboard User Manual
The SEATECH PC104/DX-440F is a compact industrial PC designed for embedded applications. It supports 486/586 CPUs, offers multiple I/O interfaces such as PC/104 bus, IDE, LCD/CRT displays, and Ethernet, and includes power management features like a watchdog timer and configurable voltage supplies.
The document details the board layout, connector pinouts, power requirements, BIOS configuration, and software considerations. It also lists supported peripherals, memory configurations, and provides troubleshooting guidance for installation and operation. This manual is written in Chinese.
Covers: Utility · Watchdog · PC/104 Bus · CPU and Memory · IDE Interface · LCD / CRT Display
SEATECH SB-810 Motherboard User Manual
This manual describes the SEATECH SB-810 motherboard, its hardware components, and how to install and configure the board in a PC system. It includes details on power requirements, CPU and memory options, and supported peripherals.
Key sections cover I/O pin assignments, BIOS configuration, video and audio settings, Ethernet, USB, IDE, and PCI options, as well as troubleshooting and safety guidelines. This manual is written in Chinese.
Covers: Product Overview · Technical Specifications · I/O Interface · BIOS Configuration · Power and Temperature · Video and LCD Configuration
Latest SEATECH manuals
SEATECH S104/sx-340 PC104 System Board User Manual
User Manual 31 pages · 111 KB · ZHThe SEATECH S104/sx-340 PC104 system board user manual provides specifications, installation, configuration, interface details, and troubleshooting guidance.
SEATECH PC104/DX-440F Embedded Industry Motherboard User Manual
User Manual 38 pages · 464 KB · ZHThe SEATECH PC104/DX-440F manual provides hardware overview, specifications, and setup instructions for the embedded PC motherboard.
SEATECH SB-810 Motherboard User Manual
User Manual 27 pages · 406 KB · ZHThe SEATECH SB-810 motherboard user manual provides an overview, specifications, I/O configuration, BIOS settings, and installation instructions.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in SEATECH manuals
How many interrupt channels does the board provide?
The S104/sx-340 provides 15 interrupt channels compatible with the 8259A interrupt controller.
What memory sizes can be installed?
It can be equipped with 8 M, 16 M, 32 M, or 64 M SDRAM modules.
From: SEATECH PC104/DX-440F Embedded Industry Motherboard User Manual
Which Ethernet speeds are available?
Both 10 M and 100 M Ethernet connections are provided.
From: SEATECH PC104/DX-440F Embedded Industry Motherboard User Manual
