Featured SCHMERSAL manuals
SCHMERSAL MSP452 Raised Round control Switch MSP452-11/11y Manual
The MSP452 cam control switch is designed for high‑force applications such as machine tools, hoisting and transport equipment. Its cast‑iron housing is zinc‑ and chromium‑plated, painted, and rated IP65 for dust and water protection.
The document lists technical parameters, including insulation voltage, current ratings, temperature range, mechanical life, cam speed and torque, as well as instructions for adjusting the cam speed and selecting appropriate micro‑switch modules for different functions. This manual is written in Chinese.
Covers: Technical Parameters · Switch System · Switch Travel · Cam Speed Adjustment · Micro‑Switch Modules · Protection Rating
EEx356 Series Explosion-proof Limit Switch Manual
This manual provides the technical data and operating instructions for the EEx356 series explosion‑proof limit switches. It includes details on explosion‑proof ratings, electrical parameters, mechanical life and accuracy.
The document also describes the interchangeable parts, mounting options and safety compliance with VDE, DIN EN50018 and other standards. This manual is written in Chinese.
Covers: 技术参数 · 防爆等级 · 工作电流 · 工作温度 · 机械寿命 · 重算精度
Latest SCHMERSAL manuals
SCHMERSAL AZ 15/16 Have Single Independent Exercise Move Item Of security Switch
AZ 15/16 safety switches with separate operating elements are used to protect electrical equipment and have an IP 67 protection rating and a rated voltage of 500V.
SCHMERSAL MSP452 Raised Round control Switch MSP452-11/11y Manual
User Manual 4 pages · 506 KB · ZHThis manual provides specifications, adjustment ranges and protection details for the Schmersal MSP452 cam control switch.
EEx356 Series Explosion-proof Limit Switch Manual
User Manual 3 pages · 361 KB · ZHManual for the EEx356 series explosion‑proof limit switch, covering specifications, installation and operation.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in SCHMERSAL manuals
What IP protection rating does the MSP452 have?
The switch is rated IP65, protecting it against dust ingress and water spray.
From: SCHMERSAL MSP452 Raised Round control Switch MSP452-11/11y Manual
What is the insulation voltage rating?
The switch is rated for an insulation voltage of 250 VAC.
From: SCHMERSAL MSP452 Raised Round control Switch MSP452-11/11y Manual
What temperature range can the switch operate in?
It can operate from –20 °C up to 40 °C.
How many mechanical cycles is the switch rated for?
The mechanical life is specified as 5×10⁰ cycles.
