Featured Sanwa manuals
Sanwa SL-16/12 Product Leaflet
The SL-16/12 cutter features a compact body with a small‑diameter motor for easy handling. It is designed for straight and diagonal cutting of thin plates, delivering clean, low‑distortion cuts and fast cutting speeds. Safety is emphasized with a double‑insulated motor and no hazardous parts, allowing anyone to use it safely.
Two versions are offered: the AC100V type (SL‑16) and the cordless type (SL‑12). Both provide a 5 mm cutting width, with maximum material thickness of 1.0 mm for steel and copper and 0.6 mm for stainless steel. The cordless model includes a 3000 mAh battery and operates at 12 V DC. This manual is written in Japanese.
Covers: Features · Specifications · Cordless Set Contents · Company Information
Sanwa SB-10G Product Leaflet
The SB-10G is a small‑body, high‑efficiency portable pipe opening machine. It is lightweight, can quickly process standard welding fittings, works on various metals while minimizing oxidation, and can handle convex or concave corners with simple operation. The tool allows re‑grinding of the workpiece, outer‑side pipe opening, and features a double‑insulated motor for safety.
Key specifications include a maximum opening capacity of 107 × 71 mm, opening width/depth of 67 × 42 mm, adjustable opening angle up to 45°–375°, processing speed of 2.5 mm/min, plate thickness range of 4–25 mm, and a rated power of 2200 W at 200 V. The machine weighs 132 kg and can handle pipe inner diameters down to 80 mm and minimum radii of 40 mmR. This manual is written in Japanese.
Covers: Features · Technical Specifications · Contact Information
Sanwa 100-SNC023 Installation Guide
This guide explains how to safely assemble the Sanwa 100‑SNC023 office chair. It includes a parts list, safety precautions, and detailed instructions for attaching the leg frame, casters, gas cylinder, seat, backrest, and arm pads. The manual also provides adjustment tips and maintenance recommendations.
The chair measures 700 mm wide, 730 mm deep, and 1080‑1180 mm high with a seat height of 450‑550 mm. Components are made from plywood, urethane foam, nylon, and PU leather. Regular bolt tightening every two months is advised to ensure safety. This manual is written in Japanese.
Covers: Safety Precautions · Parts List · Assembly Steps · Seat and Backrest Installation · Adjustment and Use · Dimensions and Materials
Sanwa 100-SPT001 Partition Assembly Manual
This manual explains how to safely assemble the Sanwa 100‑SPT001 indoor partition. It includes detailed safety precautions such as wearing gloves, avoiding use on uneven or windy locations, and never moving the partition after assembly without securing the adjusters. The document also warns against using non‑specified parts and outlines the risks of improper assembly.
The guide lists all components (2 stands, 4 adjusters, steel frame, polycarbonate panel, M4 × 12 mm screws) and provides the exact dimensions (800 mm × 400 mm × 1600 mm). Maintenance tips cover cleaning with a soft cloth, avoiding solvents, and checking that all screws are tightened before use. This manual is written in Japanese.
Covers: Safety Precautions · Parts List · Dimensions · Materials · Assembly Procedure · Maintenance
Latest Sanwa manuals
SANWA PC5000 Manual
The document introduces the features and characteristics of a digital multimeter called PC520M. The multimeter features AC True RMS, 5000 counts, 0.08% basic accuracy, selectable 5 sensitivity for Hz measurement, 0.01 ohm resolution, 0.01mV AC/DC resolution, K-type temperature measurement ranging from -50°C to 1000°C, capacitance measurement range from 0.01nF to 9.999mF, auto power off, fast response continuity buzzer, fast speed bargraph display, tilt stand, set off beeper, and protective holster. Additionally, the multimeter has a data logging mode with a built-in memory that can log 43000 data points. The logged data can be viewed and scrolled on the LCD screen, and the maximum and minimum data can also be displayed on the screen. The maximum and minimum logged data points can be searched, and the measurement interval can be selected from 0.05s, 1s, 20s, 40s.
Sanwa SL-16/12 Product Leaflet
Product Leaflet 1 pages · 575 KB · JAThe Sanwa SL-16/12 cutter provides high cutting speed, clean cuts and easy blade changes for both AC and cordless models.
Sanwa SB-10G Product Leaflet
Product Leaflet 1 pages · 628 KB · JAThe Sanwa SB-10G is a compact, lightweight portable pipe opening machine with detailed specifications and features.
SANWA 100-SNC010 Manual
Sanwa 100-SNC023 Installation Guide
Installation Guide 2 pages · 247 KB · JAStep‑by‑step assembly instructions and parts list for the Sanwa 100‑SNC023 office chair.
Sanwa 100-SPT001 Partition Assembly Manual
User Manual 1 pages · 84 KB · JAThe Sanwa 100-SPT001 Partition Assembly Manual provides step‑by‑step instructions, safety warnings, and specifications for safe setup.
SANWA 400-DFF005 Manual
Sanwa CD721 Digital Multimeter User Manual
User Manual 32 pages · 1 MB · JAThe Sanwa CD721 digital multimeter user manual provides safety instructions, operation guides, measurement methods, and full specifications.
SANWA EM7000 Manual
Which document do I need?
Installation Guide
Mounting, wiring and first power-up. Read it before the hardware goes in.
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in Sanwa manuals
What is the cutting speed of the Sanwa SL-16/12?
The AC model cuts at 8.4 mm/min and the cordless model cuts at 8.0 mm/min.
How thick a material can the cutter handle?
It can cut up to 1.0 mm thick steel or copper and up to 0.6 mm thick stainless steel.
What plate thickness range can be set on the SB-10G?
The machine can be set for plate thicknesses from 4 mm to 25 mm.
How much power does the SB-10G consume?
It has a rated power consumption of 2200 W.
How many M6×20 bolts are required for assembly?
The manual lists five M6×20 bolts for the leg frame.
How often should the bolts be retightened?
Bolts and screws should be retightened every two months.
