Featured SANLIN manuals
SANLIN Switch Mode Power Transformers Product Leaflet
The SANLIN switch mode power transformer series is designed for a wide range of applications such as DC‑DC, AC‑DC‑AC, UPS, telecommunications, computers, medical equipment and household appliances. The catalog lists many model numbers (e.g., EER28L12, EER40L12, ED28S14) and provides dimensions, core types and material options.
Key features include high efficiency, low leakage inductance, good heat dissipation and low EMI. Electrical specifications cover operating frequencies from 25 kHz to 500 kHz, power ranges from 10 W to 500 W, and operating temperatures from –40 °C to 85 °C. Various core materials (EE, EC, EI, EF, SP3, SP4, etc.) and installation options are offered to meet customer requirements. This manual is written in Chinese.
Covers: Features · Applications · Electrical specifications · Dimensions · Typical applications · Choke coils
Latest SANLIN manuals
SANLIN Switch Mode Power Transformers Product Leaflet
Product Leaflet 20 pages · 999 KB · ZHTechnical overview of SANLIN switch mode power transformers, including features, specifications and typical applications.
Questions answered in SANLIN manuals
What is the operating frequency range of SANLIN switch mode power transformers?
The transformers operate from 25 kHz up to 500 kHz.
What power range do SANLIN switch mode power transformers cover?
They are available for power ratings between 10 W and 500 W.
