Featured SAMSON-T manuals
SAMSON-T 8015 Series 240 Pneumatic Control Valve Type 3241-1/3241-7 Technical Data
The SAMSON‑T 8015 Series 240 pneumatic control valve family provides globe‑type valves (Type 3241‑1 and 3241‑7) for process engineering and industrial applications. Available in nominal sizes DN 15 to DN 300 and nominal pressures PN 10 to PN 40, the valves operate over a temperature range of –196 °C to 450 °C.
The modular design allows selection of body materials (cast iron, spheroidal graphite iron, cast steel, stainless steel, forged steel, etc.), sealing options (metal sealing, soft sealing, high‑performance metal sealing) and accessories such as positioners, solenoid valves and flow dividers. Detailed dimensions, weights and Kys flow‑coefficient tables are provided for each version.
Covers: Application · Versions · Principle of operation · Fail‑safe positions · Technical data (Table 1) · Materials (Table 2)
Latest SAMSON-T manuals
SAMSON-T 8015 Series 240 Pneumatic Control Valve Type 3241-1/3241-7 Technical Data
Datasheet 8 pages · 313 KB · ENTechnical data for SAMSON-T 8015 Series 240 pneumatic control valves (Type 3241‑1 and 3241‑7) including sizes, pressures, materials and dimensions.
Which document do I need?
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in SAMSON-T manuals
What are the fail‑safe positions of the valve?
If the actuator stem extends (FA) the valve closes on air failure; if the actuator stem retracts (FE) the valve opens on air failure.
From: SAMSON-T 8015 Series 240 Pneumatic Control Valve Type 3241-1/3241-7 Technical Data
Which materials can be used for the valve body?
The valve body can be made of cast iron, spheroidal graphite iron, cast steel, cast stainless steel, forged steel, forged stainless steel, or special materials on request.
From: SAMSON-T 8015 Series 240 Pneumatic Control Valve Type 3241-1/3241-7 Technical Data
