Featured Riegl manuals
RIEGL LPM-321 Long distance from 3D laser Terrain Measure Amount system Manual
The RIEGL LPM-321 is a high‑precision, long‑range 3D laser terrain measurement system capable of measuring objects up to 6000 m away with 15 mm accuracy. It offers multiple operation modes, including full‑automatic and manual control, and can process multiple echo signals for vegetation removal and object classification.
The system integrates a high‑speed digital signal processor, full‑waveform analysis, and optional high‑resolution camera for generating dense point clouds, TIN surfaces, and orthophotos. It includes Ethernet TCP/IP data transfer, supports various software for data processing, and meets IP64 environmental protection standards. This manual is written in Chinese.
Covers: Introduction · Operation Principle · Specifications · Dimensions · Technical Parameters · Applications
RIEGL VZ-1000 3D Laser Scanning Imaging System Preliminary Datasheet
The VZ-1000 provides ultra‑fast data acquisition with a scanning rate of up to 300,000 points per second and an angular resolution of 0.0005°. It can measure distances up to 1400 m and delivers a 100° × 360° field of view, making it suitable for surveying, archaeology, tunnel mapping, and city‑scale 3D modeling.
The system includes multiple data interfaces (LAN 10/100/1000 MBit/s, WLAN, USB 2.0), built‑in 32 GB flash storage, and optional external USB drives. Power is supplied by a rechargeable NiMH battery pack or an external 11‑32 V DC source, with smart power management and an IP64 protection rating for harsh environments.
Covers: System Overview · Scanning Performance · Data Interfaces · Power and Battery · Physical Specifications · Safety and Compliance
Latest Riegl manuals
RIEGL LPM-321 Long distance from 3D laser Terrain Measure Amount system Manual
User Manual 4 pages · 1.6 MB · ZHThe RIEGL LPM-321 user manual provides operating instructions, specifications, and safety information for the long‑range 3D laser terrain measurement system.
RIEGL VZ-1000 3D Laser Scanning Imaging System Preliminary Datasheet
Datasheet 4 pages · 536 KB · ENThe RIEGL VZ-1000 is a high‑speed, long‑range 3D laser scanning imaging system offering up to 300,000 points per second, 0.0005° angular resolution, and…
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in Riegl manuals
What is the maximum measurement range of the RIEGL LPM-321?
The LPM-321 can measure objects up to 6000 m away.
From: RIEGL LPM-321 Long distance from 3D laser Terrain Measure Amount system Manual
What measurement accuracy does the LPM-321 provide?
It delivers a measurement accuracy of 15 mm.
From: RIEGL LPM-321 Long distance from 3D laser Terrain Measure Amount system Manual
What is the maximum scanning range of the VZ-1000?
The VZ-1000 can measure up to 1400 m under optimal conditions.
From: RIEGL VZ-1000 3D Laser Scanning Imaging System Preliminary Datasheet
How many points per second can the VZ-1000 emit?
It can emit up to 300,000 points per second.
From: RIEGL VZ-1000 3D Laser Scanning Imaging System Preliminary Datasheet
