Raychem TA Thermostat User Manual
This manual describes the Raychem TA floor‑heating thermostat, including its digital LCD display, selectable room‑temperature or floor‑temperature sensing, and various operating modes such as timed low‑temperature, fast heating, and humidity measurement. It also outlines safety features, sensor fault handling, and the IP21 protection rating.
Technical details cover the 220 V, 50/60 Hz power supply, current limits (16 A main, 13 A output), temperature measurement ranges for floor (+5 °C ~ +35 °C) and room (+5 °C ~ +40 °C), overall operating limits (0 °C ~ +40 °C, extended –20 °C ~ +50 °C), dimensions (82 mm × 82 mm × 54 mm), white RAL9010 finish, and NTC 10 kΩ/25 °C sensors. This manual is written in Chinese.
Covers: Operation Modes · Technical Specifications · Installation and Wiring · Dimensions and Appearance · Safety and Compliance
Raychem T2Red Self-Regulating Heating Cable Installation Guide
The Raychem T2Red self‑regulating heating cable is designed for low‑profile floor heating in residential and commercial spaces. It can be installed under various floor types such as cement, stone, marble, and wood, providing efficient and safe surface heating.
The document includes technical specifications, recommended installation practices, compatible floor materials, packaging part numbers, and safety compliance information to ensure proper and reliable operation of the heating system. This manual is written in Chinese.
Covers: Product Overview · Technical Specifications · Installation Guidelines · Packaging and Part Numbers · Safety and Compliance
Latest Raychem manuals
Raychem RNF-100
Raychem TA Thermostat User Manual
User Manual 2 pages · 1.9 MB · ZHThe Raychem TA thermostat manual provides operation modes, specifications, and wiring information for floor heating control.
Raychem T2Red Self-Regulating Heating Cable Installation Guide
Installation Guide 2 pages · 939 KB · ZHThis guide provides installation instructions, specifications, and packaging details for the Raychem T2Red self‑regulating heating cable.
