Featured QM-AN-01 manuals
QM AN-01 Emergency Start/Stop Box User Manual
The QM AN-01 Emergency Start/Stop Box supplies emergency start and stop signals to a gas fire‑extinguishing controller. It is mounted outside the protected area exit and uses a keyed rotary switch for manual activation.
The manual lists technical parameters, wiring diagrams, terminal assignments, installation dimensions, and safety precautions. It also describes the required power cable size and advises that installation and commissioning be performed by qualified personnel. This manual is written in Chinese.
Covers: Overview · Technical Parameters · Installation and Wiring · Operating Instructions · Installation and Safety Precautions
Latest QM-AN-01 manuals
QM AN-01 Emergency Start/Stop Box User Manual
User Manual 2 pages · 260 KB · ZHThe QM AN-01 Emergency Start/Stop Box manual provides installation, wiring, and operating instructions for gas fire‑extinguishing systems.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in QM-AN-01 manuals
What is the working voltage of the QM AN-01 box?
It operates on a 24 V DC supply.
How can the gas release be stopped if no fire is detected?
Rotate the stop key to the stop position, which opens contacts 3 and 4 and interrupts the release signal.
