PowTech models by category
Featured PowTech manuals
POWTECH PT4554D Non-isolated Buck-type LED Constant Current Driver Chip Datasheet
PT4554D is a non‑isolated buck‑type LED constant‑current driver chip designed for 85Vac‑265Vac input voltage range. The chip integrates a 500V power MOS, high‑voltage supply circuitry and current‑sampling circuit, allowing a very small bill of materials and high efficiency (up to 93%).
The device offers +/-3% current accuracy, excellent line and load regulation, and protection functions such as LED short‑circuit protection and over‑temperature current reduction. It is available in SOT33‑4, SOP‑7 and ESOP‑8 packages for various LED lighting applications. This manual is written in Chinese.
Covers: Overview · Pin Definition · Electrical Parameters · Typical Application Circuit · Functional Description · Package Information
Powtech PT500 Series Soft Starter Product Catalog
The Powtech PT500 series soft starters are high‑performance motor control devices covering power ratings from 5.5 kW to 400 kW. The catalog provides detailed model specifications, installation dimensions, wiring configurations, and keyboard operation instructions for each variant.
In addition to technical data, the document includes quality‑service details such as a 24‑month warranty, technical support hours, and contact information for Powtech’s global service network.
Covers: Product Introduction · Model Specifications · Installation Dimensions · Wiring Diagrams · Keyboard Operation · Technical Parameters
PowerTech PT4201 LED Driver Datasheet
The PT4201 LED driver supports 1 W to 30 W output power and provides constant‑current regulation with low EMI and high efficiency. It includes over‑current (OCP), over‑voltage (OVP) and undervoltage lock‑out (UVLO) protections, and can be driven by an external PWM signal.
The device is supplied in a 6‑lead SOT‑23‑6 package, operates from a VDD range of 10 V‑30 V (up to 37 V absolute maximum), and features a programmable oscillator (Rosc) for setting the PWM frequency. Detailed pin definitions, electrical characteristics, and typical application circuits are provided in the datasheet. This manual is written in Chinese.
Covers: Features · Pin Description · Electrical Specifications · Protection Functions · Typical Application Circuit · Thermal Characteristics
PowTech PT4115 LED Constant Current Driver Datasheet
The PT4115 is a high‑dimming‑ratio LED constant‑current driver that operates from an input voltage of 8 V to 30 V and can deliver up to 1.2 A of LED current. It features a DIM pin for analog and PWM dimming, over‑heat protection, and low standby current.
Typical applications include automotive LED strips, low‑voltage LED spotlights, and backup lighting. The device is supplied in an SOT‑89‑5 package and requires only a few external components such as an inductor and a current‑sense resistor. This manual is written in Chinese.
Covers: Overview · Features · Pin Description · Electrical Parameters · Typical Application Circuit · Package Information
Latest PowTech manuals
POWTECH PT4554D Non-isolated Buck-type LED Constant Current Driver Chip Datasheet
Datasheet 10 pages · 550 KB · ZHThe POWTECH PT4554D is a high‑precision non‑isolated buck‑type LED constant‑current driver chip with up to 93% efficiency and built‑in protection features.
Powtech PT500 Series Soft Starter Product Catalog
Product Leaflet 7 pages · 7 MB · ENPowtech PT500 series soft starter catalog with specifications, wiring diagrams, and service information.
PowerTech PT4201 LED Driver Datasheet
Datasheet 7 pages · 583 KB · ZHThe PT4201 is a 1 W‑30 W high‑efficiency LED driver with constant‑current control, multiple protection features and a SOT‑23‑6 package.
PowTech PT4115 LED Constant Current Driver Datasheet
Datasheet 15 pages · 938 KB · ZHThe PT4115 is a 30 V, 1.2 A LED constant‑current driver with dimming and over‑heat protection.
Micro Bridge PT4207 LED Driver Datasheet
Datasheet 6 pages · 697 KB · ZHThe PT4207 is a high‑voltage drop‑mode LED driver with a wide 18‑450 V input range, internal 330 mA switch, PWM dimming and multiple protection features.
POWTECH PT4115LED Constant current driver Manual
PowTech PT4107_DB03 LED Driver Manual
User Manual 8 pages · 850 KB · ZHThe PowTech PT4107_DB03 manual details specifications, wiring, and safety for the 20W LED daylight lamp constant current source.
PowTech PT4201_DB1 Manual
Which document do I need?
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in PowTech manuals
What input voltage range does the PT4554D support?
It supports a wide input range from 85Vac to 265Vac.
From: POWTECH PT4554D Non-isolated Buck-type LED Constant Current Driver Chip Datasheet
What protection features are built into the PT4554D?
The chip includes LED short‑circuit protection and over‑temperature current reduction protection.
From: POWTECH PT4554D Non-isolated Buck-type LED Constant Current Driver Chip Datasheet
What warranty does Powtech provide for its soft starters?
Powtech offers a 24‑month warranty from the date of manufacture, with repair or replacement services.
What is the input voltage range for the PT4201?
The PT4201 operates from 10 V to 30 V typical input voltage, with an absolute maximum of 37 V.
What package does the PT4201 use?
The device is supplied in a 6‑lead SOT‑23‑6 package.
What is the maximum output current the PT4115 can provide?
It can deliver up to 1.2 A of constant LED current.
