Featured PowerMax manuals
PowerMax Wireless Alarm Control System Installation Manual
This manual provides step‑by‑step instructions for installing the PowerMax wireless alarm control system. It covers unpacking, power connection, mounting the control board on its wall‑mounted bracket, and wiring of AC transformers, RS‑232 modules and optional X‑10 sirens.
The guide also details programming of zones, compatible detectors and transmitters, diagnostic tests, battery backup procedures, and troubleshooting of common faults. Appendices list detector and transmitter configurations and offer templates for installation planning. This manual is written in Chinese.
Covers: Unpacking and Power Connection · Mounting the Control Board and Bracket · Wiring and Connector Installation · RS‑232 Module Installation · X‑10 Siren Installation · Programming Zones and Devices
Latest PowerMax manuals
PowerMax Wireless Alarm Control System Installation Manual
Installation Guide 38 pages · 1.3 MB · ZHInstallation guide for the PowerMax all‑monitor wireless alarm control system, covering setup, wiring, programming and testing.
Which document do I need?
Installation Guide
Mounting, wiring and first power-up. Read it before the hardware goes in.
Questions answered in PowerMax manuals
How many zones does the PowerMax system support?
The system supports 29 wireless zones and one hard‑wired zone (No. 30).
From: PowerMax Wireless Alarm Control System Installation Manual
What battery options are provided for backup power?
Backup power can be supplied by six AA alkaline batteries (1.8 Ah) or six AA Ni‑Mn rechargeable batteries (650 mAh).
From: PowerMax Wireless Alarm Control System Installation Manual
