Key facts
- Manuals
- 10
- Models
- 1
- Languages
- ZH
- Last added
- 2012-03-13
PowerLink models by category
Featured PowerLink manuals
PowerLink FC2011 Electric Dynamometer Controller User Manual
The FC2011 controller is used with electric dynamometers to measure and control torque, speed, power, and oil consumption. It employs a digital incremental PID control algorithm and offers high‑precision measurement with a built‑in LCD display.
The device supports RS232 and CAN communication, multiple voltage/current output options (0‑5 V, 0‑10 V, 4‑20 mA, 0‑10 mA, 0‑20 mA), and provides configurable sensor parameters, temperature compensation, and alarm functions through its menu system. This manual is written in Chinese.
Covers: Overview · Main Performance Features · Technical Specifications · Parameter Display · Parameter Setting Interface · Operation Instructions
Xydc Slip Ring User Manual
This manual describes the main applications, technical performance, working principle and structure of Xydc slip rings. It provides guidance on how to install, operate and maintain the devices, including dimensional data and part lists.
The document includes detailed specifications such as size ranges, accuracy, resistance, and operating temperature limits, as well as step‑by‑step instructions for mounting and servicing the slip rings. This manual is written in Chinese.
Covers: Main Applications · Technical Performance · Working Principle and Structure · Installation and Maintenance · Dimensions and Mounting · Parts List
POWERLink EP seriesWPS1000 Machine Group technology data
The PowerLink WPS1000 is a three‑phase generator set designed for communications, industrial, mining, military and other outdoor applications. It delivers up to 800 kW (1000 kVA) at 380‑440 V, 50 Hz, with a rated speed of 1500 rpm and a noise level of 100 dB.
The unit combines a Perkins 4008TAG2A engine with a LSA50.2S4 generator, offering high efficiency (96.39 %), low harmonic distortion (<2 %) and robust control options via PLC‑702 or PLC‑5220 modules. Dimensions are 4550 × 2060 × 3080 mm and the weight is 7585 kg. This manual is written in Chinese.
Covers: Technical Data · Engine and Generator Parameters · Performance Specifications · Control System · Dimensions and Weight · Optional Configurations
Endologix Powerlink IntuiTrak Transport System Manual
The Endologix Powerlink system, together with the IntuiTrak transport system, is a single‑use, endovascular device for treating abdominal aortic aneurysms (AAA). It consists of a self‑expanding ePTFE‑covered stent graft and optional extension components that are delivered via disposable catheters.
The manual provides device description, indications, contraindications, warnings, implantation procedure, MRI compatibility, adverse event reporting, device tracking, and return instructions. It is intended for trained physicians and their interventional teams. This manual is written in Chinese.
Covers: Device Introduction · Indications · Contraindications · Warnings and Precautions · Patient Selection, Treatment and Follow‑up · Implant Procedure
Latest PowerLink manuals
PowerLink FC2011 Electric Dynamometer Controller User Manual
User Manual 29 pages · 259 KB · ZHThe PowerLink FC2011 manual provides operating instructions, parameter settings, and interface details for the electric dynamometer controller.
Xydc Slip Ring User Manual
User Manual 8 pages · 144 KB · ZHTechnical manual for Xydc slip rings covering usage, installation, specifications and maintenance.
PowerLink SG series Hydraulic Dynamometer Implement Manual
PowerLink PCI T200 Torque measurement Amount Card Manual
POWERLink EP seriesWPS1000 Machine Group technology data
Datasheet 5 pages · 258 KB · ZHTechnical specifications and performance data for the PowerLink WPS1000 generator set.
POWERLink EP seriesWPS1000S Machine Group technology data
PowerLink Slip ring Manual
Endologix Powerlink IntuiTrak Transport System Manual
User Manual 37 pages · 1 MB · ZHInstructions for use, safety, and clinical information for the Endologix Powerlink system for abdominal aortic aneurysm treatment.
PowerLink engine MeasurementandControl system software Manual
PowerLink cgk Dynamometer Machine controller Manual
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in PowerLink manuals
What communication interfaces does the FC2011 support?
The controller provides both an RS232 serial port and a CAN interface for communication.
From: PowerLink FC2011 Electric Dynamometer Controller User Manual
How are measurement parameters displayed on the controller?
All measured values such as torque, speed, power and oil consumption are shown on the built‑in LCD screen.
From: PowerLink FC2011 Electric Dynamometer Controller User Manual
How is the slip ring installed?
For the shaft‑type slip ring, the measured shaft is placed inside the slip ring body and secured with nuts at both ends.
What is the rated power of the WPS1000?
The WPS1000 is rated at 800 kW (1000 kVA) when supplied at 380 V.
From: POWERLink EP seriesWPS1000 Machine Group technology data
Which engine brand is used in the WPS1000?
The generator set uses a Perkins engine.
From: POWERLink EP seriesWPS1000 Machine Group technology data
What is the intended use of the Powerlink system?
The Powerlink system and its extension components are intended for endovascular treatment of abdominal aortic aneurysm (AAA) in patients suitable for such repair.
