POF-LINK models by category
Featured POF-LINK manuals
POF-LINK EFS-3424 Fiber Ethernet Switch User Manual
The EFS-3424 is a 24‑port 100BASE‑FX fiber Ethernet switch with two Gigabit SFP slots, designed for department‑level networking in enterprises or campuses. It supports VLANs, link aggregation, QoS, and basic security features such as broadcast storm control.
The manual covers hardware specifications, power requirements, environmental limits, and management options (SNMP, RS‑232). Installation notes, port configuration, and troubleshooting guidance are also included to help users set up and maintain the device safely. This manual is written in Chinese.
Covers: Product Features · Technical Specifications · Physical and Environmental Parameters · Network Management · Installation and Use Precautions
POF-LINK EFS-3424 Optical Fiber Ethernet Switch User Manual
The EFS-3424 is a department‑level, layer‑2 Ethernet switch offering 24 100BASE‑FX (100 Mbps) fiber ports and two Gigabit SFP ports for flexible fiber backbone connections. It supports VLANs, priority queues, link aggregation, and basic security features such as broadcast‑storm control, making it suitable for enterprise or campus networks.
The manual covers network management via SNMP and port mirroring, physical dimensions (441 mm × 230 mm × 44 mm, 1U rack‑mountable, 7.5 kg), power requirements (110‑240 V AC, 65 W max), and environmental limits (0‑40 °C, 10‑90 % RH non‑condensing). Installation precautions and indicator descriptions are also included. This manual is written in Chinese.
Covers: Product Features · Network Management · Technical Specifications · Physical and Environmental Parameters · Management and Configuration · Installation and Use Precautions
Latest POF-LINK manuals
POF-LINK EFS-3424 Fiber Ethernet Switch User Manual
User Manual 2 pages · 326 KB · ZHThe POF-LINK EFS-3424 manual provides specifications, installation steps, and management features for the 24‑port fiber Ethernet switch with 2 SFP uplinks.
POF-LINK EFS-3424 Optical Fiber Ethernet Switch User Manual
User Manual 2 pages · 326 KB · ZHThe POF-LINK EFS-3424 user manual provides specifications, configuration, and management details for the 24‑port 100BASE‑FX and 2‑port Gigabit SFP Ethernet…
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in POF-LINK manuals
How many 100BASE‑FX fiber ports does the EFS-3424 have?
The switch provides 24 independent 100BASE‑FX fiber ports.
What is the maximum power consumption of the switch?
The internal power consumption is up to 65 W.
How many 100BASE‑FX ports does the EFS-3424 have?
The switch provides 24 100BASE‑FX (100 Mbps) fiber ports.
From: POF-LINK EFS-3424 Optical Fiber Ethernet Switch User Manual
Does the EFS-3424 support link aggregation?
Yes, it supports 802.3ad LACP link aggregation.
From: POF-LINK EFS-3424 Optical Fiber Ethernet Switch User Manual
