Featured NSIWAY manuals
Nsiway NNSS44220033 D-Class Audio Amplifier User Manual
The NNSS44220033 is a 3 W dual‑channel D‑class audio power amplifier that offers ultra‑low EMI without the need for external filters. It uses a filter‑free PWM modulation structure, built‑in feedback resistors, and EMI‑enhancement technology to achieve high efficiency (up to 85 %) and robust protection (over‑current, over‑temperature, undervoltage). The device is supplied in an SOP16 package and operates from 3.0 V to 5.25 V.
The manual covers functional description, key features, application areas such as laptops and low‑voltage audio systems, typical application circuits, absolute maximum ratings, electrical characteristics, pin assignments, and packaging details. Guidance on layout, decoupling, and EMI mitigation is also provided to help designers integrate the amplifier into portable audio products. This manual is written in Chinese.
Covers: Function Description · Key Features · Application Areas · Typical Application Circuits · Absolute Maximum Ratings · Electrical Characteristics
Nsiway NNSS44115500 Audio Power Amplifier User Manual
The NNSS44115500 (NS4150) is a Class‑D audio power amplifier designed for ultra‑low EMI operation without the need for an external output filter. It delivers up to 3 W into a 4 Ω load from a 5 V supply, achieves up to 90 % efficiency, and includes built‑in over‑current, over‑temperature, and undervoltage protection.
Typical applications include MP3/PMP players, mini speakers, and digital photo frames. The manual provides functional descriptions, pin assignments for MSOP‑8 and SOP‑8 packages, electrical specifications, and guidance on layout, decoupling, and optional external components such as inductors and capacitors for optimal performance. This manual is written in Chinese.
Covers: Function Description · Key Features · Application Areas · Typical Application Circuit · Absolute Maximum Ratings · Electrical Characteristics
Nsiway NNSS88225588 Audio Amplifier User Manual
The NNSS88225588 is an integrated‑boost audio power amplifier featuring ultra‑low noise, built‑in distortion‑free (NCN) protection and selectable AB/D class operation. It delivers 3 W per channel from a 3.7 V battery into a 4 Ω load and includes over‑current, over‑temperature and undervoltage safeguards.
The document provides functional descriptions, key specifications, pin assignments, typical application circuits, layout recommendations, test setups and package dimensions, guiding designers through implementation and performance optimization. This manual is written in Chinese.
Covers: Function Description · Key Features · Application Areas · Typical Application Circuit · Limit Parameters · Electrical Characteristics
Latest NSIWAY manuals
Nsiway NNSS44220033 D-Class Audio Amplifier User Manual
User Manual 15 pages · 842 KB · ZHThe Nsiway NNSS44220033 user manual provides specifications, features, and application guidelines for the 3 W dual‑channel D‑class audio amplifier.
Nsiway NNSS44115500 Audio Power Amplifier User Manual
User Manual 14 pages · 1.1 MB · ZHThe Nsiway NNSS44115500 is a 3 W single‑channel Class‑D audio power amplifier with ultra‑low EMI and no output filter, detailed in this user manual.
Nsiway NNSS88225588 Audio Amplifier User Manual
User Manual 17 pages · 558 KB · ZHThe manual details the NNSS88225588 integrated‑boost, low‑noise, distortion‑free 3 W×2 dual‑channel AB/D‑class audio amplifier.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in NSIWAY manuals
What is the maximum output power of the NNSS44115500?
It can deliver up to 3 W into a 4 Ω load when powered from a 5 V supply.
Does the NNSS44115500 require an external output filter?
No, the device uses a filter‑less PWM modulation structure that eliminates the need for an external LC filter.
What is the output power of the NNSS88225588 amplifier?
It delivers 3 W per channel (3 W × 2) when powered from a 3.7 V battery into a 4 Ω load.
How is the AB/D class mode switched?
The AB/D class mode is selected by a control pin that toggles high or low voltage levels.
