Featured Nexans manuals
Nexans EUROMOLD®/GPH® Compact Catalogue Connectors
The Nexans EUROMOLD®/GPH® Compact Catalogue presents a selection of medium‑voltage connectors, terminations, joints and jumpers designed for energy cables up to 42 kV and 1250 A. It includes product ranges, technical specifications, standards compliance and application examples for both indoor and outdoor installations.
The catalogue also describes the EPDM connection technology, tooling, kit contents and ordering information, highlighting the advantages of the thick‑walled conductive EPDM jacket and the integrated anti‑twist locking system.
Covers: Power accessories for energy cables · Examples of application · Specifications and standards · Technical characteristics · Kit contents · Installation overview
Nexans Essential-6 1HU 24 Cat6 Patch Panel Datasheet
The Essential-6 patch panel is built for a 19" frame, measures 1 U high and 28.4 mm deep, and provides 24 Category 6 RJ45 ports with rear LSA+ punchdown. It is available in black or grey‑white finish and includes transparent label holders for easy port identification.
The panel complies with ISO/IEC 11801:2002, supports Class E applications up to 250 MHz, and offers detailed performance values for 2‑connector channels. Installation is straightforward with IDC blocks, colour‑coded wiring (T568A/B), and optional cable‑management support.
Covers: Description · Application · Design · Performance · Installation · Technical Characteristics
Latest Nexans manuals
Nexans EUROMOLD®/GPH® Compact Catalogue Connectors
Product Leaflet 97 pages · 13.1 MB · ENA compact catalogue of Nexans EUROMOLD®/GPH® connectors, terminations, joints and jumpers for energy cables up to 42 kV and 1250 A.
Nexans Essential-6 1HU 24 Cat6 Patch Panel Datasheet
Datasheet 2 pages · 104 KB · ENThe Nexans Essential-6 1HU 24 Cat6 patch panel is a 19‑inch, unshielded, rear‑punchdown panel with 24 RJ45 ports supporting up to 250 MHz.
NEXANS - RHEYFLEX 300 500 V Description Approval Certificates VDE Reg N° 7691
RHEYFLEX® 500 -Y- is a lead-free cable with flexible cable flexibility and good chemical resistance. It is suitable for dry and moist indoor environments and for measuring, controlling, and regulating purposes. It is suitable for computer units, control equipment on machine tools assembly lines, conveyors, and production lines for controlling, regulating, and monitoring work processes. It is also suitable for industrial plants and production lines that require temporary free movement without periodic recurrence. Cross sections above 10 mm² are used as energy supply cables for fixed installations on machine tools in production lines.
Which document do I need?
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in Nexans manuals
What is the maximum voltage rating for the EUROMOLD® connectors?
The EUROMOLD® connectors are rated for up to 42 kV (some series up to 52 kV).
What material is used for the connector jacket?
The connectors use an EPDM (ethylene propylene diene monomer) jacket.
How many ports does the Essential-6 patch panel have?
It provides 24 RJ45 ports.
What is the maximum frequency supported by the panel?
The panel supports frequencies up to 250 MHz.
