Featured miTEC manuals
Mitec KU Band 20W-250W & C Band 100W-250W High Power Hub-Mount Solid-State Power Amplifiers Product Leaflet
Mitec’s high‑power hub‑mount solid‑state power amplifiers (SSPAs) are designed for satellite communications, offering reliable carrier‑grade performance in both Ku‑Band (14.0‑14.5 GHz) and C‑Band (5.85‑6.42 GHz). The amplifiers deliver output powers from 20 W to 250 W for Ku‑Band and 100 W to 250 W for C‑Band, with high linearity and efficiency across a wide temperature range.
Key features include a -40 °C to +55 °C operating temperature range, redundancy‑ready designs, lightweight compact form factor, extensive RF monitoring (output power, forward/reflected power), serial and analog M&C interfaces, and built‑in alarms for voltage, current, and temperature. Mechanical options such as IP54‑rated, field‑replaceable fans and external shrouds improve thermal management.
Covers: Product Overview · Key Features · Mechanical Features · Electrical Characteristics · Specifications · Interfaces
MBI-05/MBI-05H Bank Intercom Unit Manual
The document lists the technical parameters of the MBI-05/MBI-05H intercom, including power supply, audio characteristics, dimensions and weight. It also describes the layout of connectors, volume controls, mute function, and adjustable microphone stand.
Detailed sections explain how to connect external power, use the client and host audio jacks, adjust volume on both the host and client sides, and operate the mute button. The manual includes wiring diagrams and notes on proper polarity for the DC12 V input. This manual is written in Chinese.
Covers: Technical Parameters · Power Supply · Audio Frequency Response · Connector Layout · Volume Control · Mute Function
Latest miTEC manuals
Mitec KU Band 20W-250W & C Band 100W-250W High Power Hub-Mount Solid-State Power Amplifiers Product Leaflet
Product Leaflet 4 pages · 262 KB · ENThe Mitec high‑power hub‑mount solid‑state power amplifiers for Ku‑Band (20‑250 W) and C‑Band (100‑250 W) provide high linearity, compact size, and…
MBI-05/MBI-05H Bank Intercom Unit Manual
User Manual 2 pages · 2 MB · ZHThis manual provides specifications, functions, and operating instructions for the MBI-05 and MBI-05H bank intercom units.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in miTEC manuals
What monitoring and control interfaces are provided?
Both serial (RS485/RS232) and analog M&C interfaces are available, offering alarms for voltage, current, temperature, and status indicators such as mute, gain, and RF power detection.
What is the operating temperature range of the amplifiers?
The units operate from –40 °C up to +55 °C.
What voltage and current does the intercom require?
It requires a DC12 V supply with a current draw of 250 mA.
What is the audio frequency range of the unit?
The unit covers frequencies from 100 Hz to 16 kHz.
