Featured Microview manuals
Microview MVC1800DAM-GE30 Camera User Manual
The MVC1800DAM-GE30 is a high‑resolution black‑and‑white CCD camera designed for machine‑vision and industrial inspection. It uses a progressive‑scan sensor with electronic shutter to capture fast moving objects and offers a Gigabit Ethernet interface for data transfer.
The manual covers detailed parameters, physical dimensions, application scenarios, interface definitions, shutter and gain controls, three acquisition modes (continuous, asynchronous reset, automatic), and additional functions such as flash output and an internal watchdog for robust operation. This manual is written in Chinese.
Covers: Camera Introduction · Detailed Parameters · Physical Dimensions · Application Scenarios · Camera Connection · Interface Definition
Microview MVC610DAC-GE110 CCD Digital Camcorder User Manual
The MVC610DAC-GE110 is a high‑resolution color CCD camera designed for machine‑vision and industrial inspection. It uses a progressive‑scan sensor with an electronic shutter, supports gigabit Ethernet, and offers flexible trigger and flash control.
The manual details the camera's physical dimensions, interface definitions, shutter speed settings, gain control, and special functions such as watchdog protection and flash synchronization for continuous‑capture mode. This manual is written in Chinese.
Covers: Camera Introduction · Camera Connection · Camera Working Modes · Other Functions
Microview MVC1280SA-GE30 Camera User Manual
The MVC1280SA-GE30 series camera is designed for high‑speed industrial inspection and traffic capture. It supports Gigabit Ethernet, multiple trigger interfaces, and offers both global and rolling shutter modes.
The manual details hardware specifications, connection interfaces, multi‑camera synchronization, operating modes, and watchdog recovery functions, providing all necessary information for proper installation and use. This manual is written in Chinese.
Covers: Features · Camera Functions · Connection Interface · Multi-Camera System · Operating Modes · Self‑Recovery (Watchdog) Function
Microview MVC2010DAC-GE12 CCD Digital Camera Hardware User Manual
The MVC2010DAC-GE12 is a high‑resolution, color CCD camera designed for machine‑vision and industrial inspection applications. It uses a progressive‑scan sensor with an electronic shutter, supporting high‑speed image capture and simple, safe interfaces.
The manual covers the camera's detailed parameters, physical dimensions, and typical use cases, then describes connection interfaces, power and control pins, gain and shutter settings, three acquisition modes, external synchronization signals, sampling‑bit adjustment, and the built‑in watchdog function that protects communication stability. This manual is written in Chinese.
Covers: Camera Introduction · Camera Connection · Interface Definition · Gain and Shutter Control · Acquisition Modes · External Synchronization Control Signals
Latest Microview manuals
Microview E412 Image acquisition card Manual V1.0
E412 image acquisition card is a four-channel color/black and white image acquisition card based on PCI-E bus. It supports four-channel composite video signal real-time acquisition and display, and can stably receive standard video signals (PAL, NTSC, SECAM) from various video sources, with a maximum resolution of 768 x 576 per channel.
Microview MVC800DAC-GE45 CCD digital camcorder hardware Manual V5.0b
Microview MVC1800DAM-GE30 Camera User Manual
User Manual 12 pages · 312 KB · ZHThe Microview MVC1800DAM-GE30 camera user manual provides specifications, connection details, and operating modes for machine vision and industrial inspection.
Microview MVC610DAC-GE110 CCD Digital Camcorder User Manual
User Manual 12 pages · 288 KB · ZHHardware usage guide for the Microview MVC610DAC-GE110 CCD digital camcorder, covering specifications, connections, and operation modes.
Microview MVC1280SA-GE30 Camera User Manual
User Manual 12 pages · 530 KB · ZHHardware usage guide for the Microview MVC1280SA-GE30 industrial camera.
Microview MVC2010DAC-GE12 CCD Digital Camera Hardware User Manual
User Manual 13 pages · 285 KB · ZHThe Microview MVC2010DAC-GE12 CCD digital camera hardware user manual provides specifications, interface definitions, operation modes, and control signal…
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in Microview manuals
What interfaces does the MVC1800DAM‑GE30 camera provide?
It has a Gigabit Ethernet data interface and a 12 V power/control connector with TTL signals for flash and trigger.
How many shutter speed levels are available?
The camera offers 16 selectable shutter speed levels.
What interfaces are provided on the MVC610DAC‑GE110 camera?
The camera has a gigabit Ethernet port for data transfer and a 12 V power/control connector with pins for flash output, trigger input, and ground.
From: Microview MVC610DAC-GE110 CCD Digital Camcorder User Manual
How many shutter speed levels does the camera support?
The MVC610DAC‑GE110 offers 16 selectable shutter speed levels, ranging from 1/110 s to 1/110 000 s and a long‑integration mode.
From: Microview MVC610DAC-GE110 CCD Digital Camcorder User Manual
What is the minimum shutter time of the MVC1280SA‑GE30?
The camera can achieve a minimum shutter time of 8 µs.
How many cameras can be synchronized in a multi‑camera system?
The system supports multiple cameras; one acts as the Master and the others as Slaves.
