Matrox models by category
Featured Matrox manuals
matrox MX02 Mini
The MXO2 Mini provides HDMI, component, S‑Video, composite and RCA inputs, allowing capture and playback of HD and SD video on both Mac and Windows systems. It includes Matrox's proprietary color‑calibration feature for accurate hue, chroma, contrast, brightness and blue‑only adjustments.
The device supports real‑time up‑scaling, down‑scaling and cross‑conversion between 720×486 (NTSC), 720×576 (PAL), 1280×720 and 1920×1080 resolutions, with 10‑bit and 12‑bit video processing, and offers HDMI embedded audio up to 8 channels. It weighs 280 g and measures 166 × 110 × 40 mm. This manual is written in Japanese.
Covers: Features · Supported Video Formats · Color Calibration · Technical Specifications · Operating System Compatibility · Connections and Audio
Matrox RT.X2 User Manual
This manual introduces the Matrox RT.X2 video capture and processing card, covering its hardware features, supported video formats, and compatible software applications. It includes copyright, disclaimer, and contact information for Matrox Electronic Systems Ltd.
The document details installation steps, system requirements, and operational guidance, along with technical specifications such as input resolution and frame rates. It also lists the Windows operating systems and professional video editing tools that are supported.
Covers: Introduction · Hardware Overview · Supported Video Formats · Software Compatibility · Installation · Operation
Matrox RT.X2 User Manual
This manual covers the Matrox RT.X2 video capture card, describing its hardware features, supported video formats, and integration with a wide range of professional video software. It includes detailed instructions for installing the card, configuring drivers, and using Matrox‑provided utilities such as Mx.tools and Flex GPU.
The guide also lists compatible operating systems and applications, explains MPEG‑2 and HDV encoding options, and offers troubleshooting steps for common issues. Support resources and contact information are provided at the end of the document.
Covers: Matrox RT. X2 · Matrox RT. X2 SD LSE HDV BAT · Matrox RT. X2 #1 Video for Windows #2 FF · Matrox RT. X2 MPEG-2 · Matrox RT. X2 AUPRVER PRE · Matrox RT. X2 BER
Matrox Axio Selection Guide
The Matrox Axio series is a family of real‑time HD and SD editing platforms that integrate tightly with Adobe Production Studio software. The guide outlines three models – Axio LE, Axio HD and Axio SD – and highlights their shared high‑performance editing engine, extensive real‑time effects, and flexible workflow options.
Key differences among the models are the supported codecs, the number of video/audio I/O channels, and the ability to upgrade via optional interface boxes. All three platforms can output both HD and SD signals simultaneously and provide VU meters for audio monitoring during capture. This manual is written in Chinese.
Covers: Overview · Main Features · Real‑time Editing Engine · Real‑time Tools · Interface Boxes · Product Specification Table
Latest Matrox manuals
matrox MX02 Mini
Product Leaflet 2 pages · 774 KB · JAThe Matrox MXO2 Mini is a compact HDMI and analog video capture device for Mac and PC, offering 10‑bit scaling, color calibration and real‑time up/down…
Matrox MXO2 series products - Mac Selection Guide
Matrox RT.X2 User Manual
User Manual 208 pages · 3.4 MB · ENThe Matrox RT.X2 User Manual provides operating instructions, specifications, and setup information for the Matrox RT.X2 video capture device.
Matrox RT.X2 User Manual
User Manual 179 pages · 4 MB · ENThe Matrox RT.X2 User Manual provides setup, operation, and troubleshooting information for the Matrox RT.X2 video capture device.
Matrox Axio Selection Guide
Product Leaflet 24 pages · 2.7 MB · ZHA selection guide that compares the Matrox Axio LE, HD and SD platforms and their real‑time editing features.
Matrox Axio Installation Guide
Installation Guide 246 pages · 7 MB · ZHThe Matrox Axio Installation Guide provides step‑by‑step instructions for setting up the Axio hardware and software.
Matrox Axio Installation Guide
Installation Guide 246 pages · 7 MB · ZHThis installation guide provides step‑by‑step instructions for setting up Matrox Axio hardware and software.
Matrox RT.X2 Installation Guide
Installation Guide 39 pages · 1.6 MB · ENInstallation guide for the Matrox RT.X2 video capture card, covering hardware setup, software configuration, and system requirements.
Matrox RT.X2 User Manual
User Manual 158 pages · 3 MB · ENThe Matrox RT.X2 User Manual provides operating instructions, system specifications, and software integration details for the RT.X2 video solution.
Matrox DualHead2Go Series Manual
Matrox DualHead2Go User Manual, Introduces how to connect monitors, install software, and solve common problems
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Installation Guide
Mounting, wiring and first power-up. Read it before the hardware goes in.
Questions answered in Matrox manuals
What video input formats can the MXO2 Mini capture?
The device accepts HDMI, analog component, S‑Video, composite and RCA inputs, handling both HD and SD video.
From: matrox MX02 Mini
Does the MXO2 Mini provide color‑calibration features?
Yes, Matrox’s proprietary color‑calibration allows adjustment of hue, chroma, contrast, brightness and blue‑only for professional‑grade monitoring.
From: matrox MX02 Mini
Which operating systems does the Matrox RT.X2 support?
The card is supported on Windows platforms.
From: Matrox RT.X2 User Manual
Where can I find support for the Matrox RT.X2?
Support information is available at Matrox’s website under the video capture support section.
From: Matrox RT.X2 User Manual
What video formats does the Matrox Axio LE support?
The Axio LE supports uncompressed 8‑bit HD and SD editing, as well as DV‑1394, composite, Y/C, component and SDI inputs and outputs.
How many audio inputs and outputs are provided by the Axio HD interface box?
The Axio HD interface box provides 4‑in/8‑out AES/EBU audio and 8‑in/8‑out SDI embedded audio channels.
