Featured LENORO+BAUER manuals
Lenord + Bauer GEL 293 Incremental Encoder Technical Data Sheet
The GEL 293 is an incremental encoder with a hollow 16‑mm shaft and an integrated elastic coupling. It uses a magnetic measuring system combined with a precision toothed wheel, providing high reliability, shock resistance, and immunity to dirt, oil and water.
The document lists the encoder’s electrical output options (V, VN, T, TN, U, UN, X, XN, S, SN), current‑output ranges, mechanical dimensions, IP66 protection, temperature limits, and mounting instructions, together with a full pin‑layout and cable information.
Covers: General information · Fields of application · Measuring principle · Output signals · Current outputs · Technical data (DIN 32878)
LENORD+BAUER GEL 2443 MiniCoder Product Data Sheet
The MiniCoder GEL 2443 series is the latest evolution of LENORD+BAUER's GEL 244 sensor line, offering minimized offset values, lower power consumption, an enlarged air gap, and a more robust sensor surface. The new design includes an alternative radial cable outlet and optional 17‑pole connectors or amplitude regulation.
Key mechanical changes include a thicker flange (increased from 3.5 mm to 5 mm) and four standard cable lengths (30 cm, 150 cm, 250 cm, 600 cm). The housing is step‑free for easier integration, and high EMC/ESD stability is achieved through additional shielding, a metal cover, and a separate screen plate. The GEL 2443 can directly replace the earlier GEL 244 series.
Covers: Improved Features · Cable Options · Mechanical Changes · Installation Guidelines · EMC/ESD Stability
Latest LENORO+BAUER manuals
Lenord + Bauer GEL 293 Incremental Encoder Technical Data Sheet
Datasheet 8 pages · 175 KB · ENTechnical data sheet for the Lenord + Bauer GEL 293 incremental encoder, detailing specifications, output signals, mounting, and environmental ratings.
LENORD+BAUER GEL 2443 MiniCoder Product Data Sheet
Product Leaflet 1 pages · 42 KB · ENThe LENORD+BAUER GEL 2443 MiniCoder sensor data sheet outlines improved features, specifications, and installation notes for the updated series.
Which document do I need?
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in LENORO+BAUER manuals
What output signal patterns does the GEL 293 provide?
The encoder offers V, VN, T, TN, U, UN, X, XN, S and SN patterns, with HTL or TTL logic levels as defined for each pattern.
From: Lenord + Bauer GEL 293 Incremental Encoder Technical Data Sheet
What temperature range can the encoder operate in?
It operates from 0 °C to +70 °C normally, and from –20 °C to +85 °C with the optional temperature range.
From: Lenord + Bauer GEL 293 Incremental Encoder Technical Data Sheet
Can the GEL 2443 be used as a replacement for the GEL 244 series?
Yes, the new 2443 series can be used as a direct substitute for the 244 series.
What cable lengths are available for the GEL 2443?
Four standard cable lengths are offered: 30 cm, 150 cm, 250 cm, and 600 cm.
