Featured Kistler manuals
Kistler 5877A maXYmos TL XY Monitor User Manual
The maXYmos TL XY Monitor captures, analyzes and evaluates XY curves of two measurands that must stay in a precisely defined relationship. It is used in applications such as press fitting, riveting, turning, and shock‑absorber testing. The device can handle up to eight cascaded XY channel pairs and provides a wide range of evaluation objects for detailed curve analysis.
The system consists of a Measuring and Evaluation Module (MEM) and a Display Module (DIM). The MEM works autonomously and can be operated via Ethernet, USB or fieldbus interfaces, while the DIM offers a 10.4" colour touch screen for local control. Various mounting options (desktop, wall, DIN‑rail) and a comprehensive set of accessories allow flexible integration into test rigs.
Covers: Technical Data · System Concept · Evaluation Process · Housing Concept and Installation Variants · Accessories · Dimensions
Kistler Sensor Products Datasheet
The document presents Kistler's range of measurement sensors, including piezoelectric and piezoresistive pressure transducers, high‑impedance load cells, and K‑Shear® accelerometers. Each product entry lists key features, measurement ranges, temperature limits and typical applications such as engine development, biomechanics and industrial monitoring.
Additional sections cover signal conditioners, calibration equipment, mounting adapters and monitoring/control units that complete the measurement chain for dynamic and static applications.
Covers: Pressure Sensors · Force Sensors · Accelerometers · Signal Conditioners · Calibration Equipment · Mounting Adapters
Latest Kistler manuals
Kistler 5877A maXYmos TL XY Monitor User Manual
User Manual 9 pages · 4.4 MB · ENThe Kistler 5877A maXYmos TL XY Monitor manual describes features, technical data, installation, and operation for complex curve evaluation.
Kistler Sensor Products Datasheet
Datasheet 8 pages · 770 KB · ENA datasheet describing Kistler's pressure, force, torque and acceleration sensors and related equipment.
KISTLER Piezoresistive Pressure Sensors Manual
