Featured JYB-G manuals
Kunlun Coast Sensor JYB-G Shipboard Pressure/Level Transmitter User Manual
The JYB-G shipboard pressure/level transmitter is designed for marine applications, measuring pressure and liquid level in various ship compartments. It complies with CCS certification and offers robust anti‑corrosion, anti‑overload, and anti‑condensation features.
The manual provides detailed instructions on installation (vertical mounting, use of pressure buffering for fast pressure changes), wiring (standard HART, 4‑20 mA or 0‑5 V output), safety measures for explosive environments, maintenance, and fault diagnosis. This manual is written in Chinese.
Covers: Product Features · Main Applications · Technical Specifications · Installation · Wiring · Commissioning
Kunlun Coast Sensor JYB-G Pressure Transmitter User Manual
The JYB-G pressure transmitter is a battery‑powered, wireless‑communication device with a high‑resolution 128×64 LCD display, ultra‑low power consumption, and a fully sealed metal housing for all‑weather operation. It is designed for remote pressure monitoring in field or power‑constrained environments such as oil, gas, and heating pipelines.
The manual covers product features, primary applications, detailed technical parameters, test operation, wireless communication settings, safety guidelines, maintenance procedures, and common fault troubleshooting. It also includes instructions for battery handling, installation orientation, and proper handling in explosive or hazardous areas. This manual is written in Chinese.
Covers: Product Features Overview · Primary Applications · Technical Specifications · Test Operation · Communication Parameter Settings · Safety Instructions
Latest JYB-G manuals
Kunlun Coast Sensor JYB-G Shipboard Pressure/Level Transmitter User Manual
User Manual 3 pages · 238 KB · ZHUser manual for the JYB-G shipboard pressure and level transmitter, covering features, installation, wiring, safety, and troubleshooting.
Kunlun Coast Sensor JYB-G Pressure Transmitter User Manual
User Manual 2 pages · 438 KB · ZHThe JYB-G pressure transmitter manual provides features, specifications, installation, communication setup, safety, maintenance, and troubleshooting…
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in JYB-G manuals
How should the pressure transmitter be installed?
Mount the transmitter vertically on a flat surface and tighten it using a wrench at the bottom hex nut, avoiding rotation of the top part.
From: Kunlun Coast Sensor JYB-G Shipboard Pressure/Level Transmitter User Manual
What should I check if the transmitter shows no output signal?
Verify that the transmitter is powered, check the wiring against the wiring diagram, and ensure the correct supply voltage is applied.
From: Kunlun Coast Sensor JYB-G Shipboard Pressure/Level Transmitter User Manual
How do I disconnect the battery for test operation?
Open the rear cover and set the two jumper caps (SW1, SW2) horizontally to disconnect the battery; set them vertically to reconnect.
From: Kunlun Coast Sensor JYB-G Pressure Transmitter User Manual
How often does the transmitter send data?
The communication interval is set in the wireless controller; a value of 001 sends data every 5 seconds, other values are in minutes.
From: Kunlun Coast Sensor JYB-G Pressure Transmitter User Manual
