Featured iSpirit manuals
iSpirit 4504 Switch Quick Configuration Guide
The guide provides step‑by‑step instructions for configuring VLANs on the iSpirit 4504 switch using both PCRT (port‑based) and 802.1Q (tag‑based) methods. It covers creating VLANs, assigning ports, enabling inter‑VLAN communication, and configuring private VLANs, port isolation, STP, trunk aggregation, port mirroring, and ACLs.
Additional sections describe how to back up configuration files, upgrade the TMGE software, set SN and MK bindings, configure TIP binding, and enable 802.1X authentication. Attachments include usage instructions for the 100 Mbps module and how to configure a super terminal. This manual is written in Chinese.
Covers: VLAN configuration based on PCRT (port‑based) · VLAN configuration based on 802.1Q · VLAN inter‑communication · Private VLAN configuration · VLAN port isolation · STP (Spanning Tree Protocol) configuration
iSpirit 12800 Command Reference Manual
This manual describes the command-line interface of the iSpirit 12800 network device. It covers system management commands, file handling, interface configuration, VLAN setup, MSTP, IGMP snooping, ACLs, routing protocols and debugging utilities.
The document is organized into numbered sections, each listing the available commands, their syntax and brief usage notes. Example commands include "configure terminal" to enter configuration mode, "show log" to display system logs, and various "show" and "debug" commands for monitoring and troubleshooting. This manual is written in Chinese.
Covers: System Management · File Management · Interface Configuration · VLAN Configuration · MSTP Configuration · IGMP Snooping
Latest iSpirit manuals
iSpirit 4504 Switch Quick Configuration Guide
Quick Start Guide 56 pages · 770 KB · ZHThis quick configuration guide shows how to set up VLANs, STP, port aggregation, and other features on the iSpirit 4504 switch.
iSpirit 12800 Command Reference Manual
Programming Manual 161 pages · 1.1 MB · ZHThe iSpirit 12800 Command Reference Manual provides configuration commands for system, interface, VLAN, MSTP and other features.
Which document do I need?
Quick Start Guide
The shortest path to a working setup, usually only a few pages.
Programming Manual
Instruction set, parameters and examples for configuring or programming the device.
Questions answered in iSpirit manuals
How do I create a new VLAN on the iSpirit 4504 switch?
Enter the VLAN command, e.g., "Switch# vlan 2" to create VLAN 2.
How can I assign ports to a VLAN?
Use the untag command in VLAN configuration mode, such as "Switch(vlan2)# untag 1/1 1/3" to add ports 1 and 3 to VLAN 2.
How do you enter configuration mode on the iSpirit 12800?
Use the command "configure terminal" to enter configuration mode.
Which command displays the system log entries?
Use "show log" (or "show log [level]") to display log entries.
