Featured Infranor manuals
Infranor CD1‑k Servo Drive User Manual
The CD1‑k is a fully digital servo drive with sinus‑PWM control for brushless AC motors equipped with position sensors. It operates on 230 VAC or 400/480 VAC main voltages and communicates via CANopen. The manual covers the drive’s structure, parameter‑setting software, hardware configuration, and safety precautions.
Key sections include a step‑by‑step commissioning guide, detailed description of logical inputs, brake control, speed selection, CANopen communication profile, and an extensive troubleshooting & maintenance chapter with error codes and reset procedures. This manual is written in Chinese.
Covers: Overview · Commissioning · Parameter‑setting Software Installation · Hardware Configuration · Logical Inputs · CANopen Communication
Latest Infranor manuals
INFRANOR CD1-a series digital alternating servo driver Manual
CD1-a series is a fully digital AC servo drive with safety precautions and installation requirements. It is suitable for various electronic devices and has high sensitivity and protection functions.
Infranor CD1‑k Servo Drive User Manual
User Manual 26 pages · 414 KB · ZHThe Infranor CD1‑k manual explains installation, commissioning, CANopen communication, troubleshooting and maintenance for this digital servo drive.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in Infranor manuals
What safety precautions should be taken before handling the drive?
After power is removed, wait at least five minutes before touching the drive, ensure the unit is grounded, and avoid touching connectors or static‑sensitive parts.
