Featured ICSENSORS manuals
ICSENSORS 1451 PC Board Mountable Pressure Sensor 0-60 mV Output Gage Absolute Pressure Low Cost
The Model 1451 is a surface‑mount piezoresistive silicon pressure sensor designed for high‑volume applications that require small size, low weight, low cost, and compatibility with automated assembly equipment. It is available with either gage or absolute pressure sensing chips mounted on a ceramic substrate, with interchangeable caps for different pressure ports.
Performance specifications include a supply voltage of 3 VDC, full‑scale output span of 30‑120 mV, pressure non‑linearity of ±0.25 % span, and a weight of only 0.3 g. The sensor operates over a temperature range of –40 °C to +125 °C and offers various pressure range options from 0‑5 psi up to 0‑500 psi.
Covers: Features · Description · Standard Ranges · Performance Specifications · Ordering Information · Connections
ICSENSORS Model 1230 UltraStable PC Board Mountable Pressure Sensor 0-100 mV Output Absolute Differential Gage Wide Temperature Range Manual
The Model 1230 is a high‑performance, temperature‑compensated pressure sensor designed for cost‑sensitive applications requiring excellent stability. It offers absolute, differential, and gage pressure ranges with interchangeable span settings and low power consumption.
The datasheet lists full performance specifications, including supply current, output range, non‑linearity, hysteresis, temperature coefficients, dimensions, and ordering information, as well as wiring diagrams and factory test points for integration into process control, medical instrumentation, and airflow management systems.
Covers: Features · Description · Dimensions · Performance Specifications · Connections · Factory Test Points
Latest ICSENSORS manuals
ICSENSORS Pressure Chips series preliminary
icminer.com Electronic-Library Service CopyRight 2003
ICSENSORS 1451 PC Board Mountable Pressure Sensor 0-60 mV Output Gage Absolute Pressure Low Cost
Datasheet 3 pages · 519 KB · ENThe SUNSTAR 1451 is a surface‑mount piezoresistive silicon pressure sensor offering 0‑60 mV output for gage and absolute pressure applications.
ICSENSORS Model 1230 UltraStable PC Board Mountable Pressure Sensor 0-100 mV Output Absolute Differential Gage Wide Temperature Range Manual
Datasheet 3 pages · 746 KB · ENThe SUNSTAR 1230 PC board‑mountable pressure sensor datasheet provides specifications, features, dimensions, and connection details.
Which document do I need?
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in ICSENSORS manuals
What supply voltage does the SUNSTAR 1451 sensor require?
It requires a 3 VDC supply voltage.
From: ICSENSORS 1451 PC Board Mountable Pressure Sensor 0-60 mV Output Gage Absolute Pressure Low Cost
What is the output noise of the sensor?
The output noise is specified as 1.0 µV peak‑to‑peak.
From: ICSENSORS 1451 PC Board Mountable Pressure Sensor 0-60 mV Output Gage Absolute Pressure Low Cost
What is the supply current of the Model 1230 sensor?
The supply current is 1.5 mA.
