Key facts
- Manuals
- 3
- Models
- 1
- Languages
- ZH
- Last added
- 2011-09-29
Hydralok models by category
Featured Hydralok manuals
Hydralok HE325 Crimping Machine User Manual
The Hydralok HE325 is a hand‑operated crimping machine used to swage hose assemblies. The manual emphasizes safe operation, requiring the machine to be placed on a stable platform, wearing protective gear, and never operating it before reading the instructions.
Key sections include warranty conditions, safety regulations, technical specifications, handling and transport guidelines, preliminary checks, routine maintenance, detailed operating instructions, calibration procedures, spare‑part lists, and information on optional air‑hydraulic or electrical power packs. This manual is written in Chinese.
Covers: Safety regulations · Technical data · Operating instructions · Routine maintenance · Calibration · Optional power packs
Hydralok HE325 Crimping Machine User Manual
This manual covers the safe operation of the Hydralok HE325 hose swaging (crimping) machine, including handling, preliminary checks, lighting requirements, and step‑by‑step operating instructions. It also details routine maintenance, lubrication, calibration procedures, and optional power‑pack configurations.
Warranty conditions, technical specifications, spare‑part lists, and electrical/hydraulic connection guidelines are included to help users install, service, and keep the machine in optimal condition. This manual is written in Chinese.
Covers: Warranty Conditions · Declaration of Conformity · Safety Regulations · Technical Data · Handling / Transport · Preliminary Checks
Latest Hydralok manuals
Hydralok HE325 Crimping Machine User Manual
User Manual 19 pages · 262 KB · ZHThe manual provides safety regulations, technical data, operating instructions, maintenance, calibration, and optional power‑pack information for the…
HYDRALOK Crimping machine H32B4 Manual
Hydralok HE325 Crimping Machine User Manual
User Manual 16 pages · 262 KB · ZHThe Hydralok HE325 crimping machine user manual provides safety rules, technical data, operating instructions, maintenance and warranty information.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in Hydralok manuals
How often should the machine be lubricated?
Lubrication should be performed at least once per day, especially before large‑batch crimping operations.
What is the warranty period for the HE325 machine?
The machine is warranted for 12 months from the date of delivery, provided the sales invoice is presented.
What voltage options are available for the optional electrical power pack?
The optional electrical power pack can be supplied with 220 V single‑phase 50 Hz or 12 V DC.
