Featured HANTRONIX manuals
HDM 3224TS-1 Dimensional Drawing
The document provides a dimensional drawing of the HDM 3224TS-1 display module, including overall size (167.0 mm × 109.0 mm × 13.0 mm), viewing area (122.0 mm × 92.0 mm), dot pitch (0.36 mm × 0.36 mm) and connector information such as the MOLEX 52271‑2090 mating for the touch panel.
Electrical characteristics are listed, covering supply voltages (30.0 V for the LCD, 7.0 V for the backlight), operating temperature range (0 °C to 50 °C), storage temperature (‑20 °C to 70 °C), and pin assignments for power, ground and data signals.
Covers: Dimensional Drawing · Connector Information · Touch Screen · Physical Data · Electrical Characteristics · Absolute Maximum Ratings
Latest HANTRONIX manuals
HANTRONIX HDM3224TS-2 DATA SHEET
The document describes the features and characteristics of a 320 x 240 dots graphic module with CCFL backlight and touch screen. It operates on supply voltages of 5V and 27V, and is suitable for STN/black and white and FSTN displays. The module has dimensions of 168.0W x 111.0H x 9.0T mm, a viewing area size of 120.0W x 90.0H mm, and a dot pitch of 0.36W x 0.36H mm.
HDM 3224TS-1 Dimensional Drawing
Datasheet 1 pages · 32 KB · ENDimensional drawing and specifications for the HDM 3224TS-1 graphic CCFL backlight display with touch screen.
Which document do I need?
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in HANTRONIX manuals
What is the input voltage for the module?
The module requires an input voltage of 70 V.
What is the maximum size of the touch screen?
The touch screen size is limited to 13.0 mm.
