Featured GuardShield manuals
GuardShield Safe 4 Safety Light Curtain User Manual
This manual covers the GuardShield Safe 4 safety light curtain, a Class 4 ESPE device used for point‑of‑contact (POC) and perimeter (PAC) protection on hazardous machinery. It details the product’s features, operating principle, and the required safety precautions for qualified personnel.
Key sections include installation and assembly steps, calibration procedures, wiring diagrams, safety distance calculations (OSHA, ANSI, European), troubleshooting, and regular inspection guidelines. The document also lists technical specifications, part numbers, and certification information. This manual is written in Chinese.
Covers: Introduction · Safety Guidelines · Professional Personnel · Application Range · Correct Use · General Protection Measures
GuardShield Micro 400 Light Curtain User Manual
The GuardShield Micro 400 user manual provides safety guidelines for the application, installation and maintenance of the solid‑state safety light curtain. It includes compliance information, wiring diagrams, connector details and recommended power supply.
The document also lists technical specifications such as IP69K protection, IEC 61496 compliance, EN ISO 13849 SIL rating, +24 V DC supply and M12 connector type, as well as part numbers and ordering information.
Covers: Safety Guidelines · Installation · Wiring Diagram · Power Supply · Compliance and Standards · Technical Specifications
Latest GuardShield manuals
GuardShield Safe 4 Safety Light Curtain User Manual
User Manual 42 pages · 5.9 MB · ZHThe GuardShield Safe 4 safety light curtain user manual provides installation, operation, safety guidelines, calibration, and maintenance instructions.
GuardShield Micro 400 Light Curtain User Manual
User Manual 40 pages · 5.4 MB · ENUser manual for the GuardShield Micro 400 safety light curtain covering safety guidelines, installation, wiring and specifications.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in GuardShield manuals
What is the maximum protection width for GuardShield Safe 4 with a 14 mm resolution?
The maximum protection width is 0 – 9 m.
Can GuardShield Safe 4 be used with machines that cannot be stopped in an emergency?
No, it must not be used with machines that cannot be power‑off in an emergency.
What safety standards does the GuardShield Micro 400 meet?
It complies with IEC 61496‑1, IEC 61496‑2, and EN ISO 13849 with a SIL C rating.
What is the IP rating of the GuardShield Micro 400?
The curtain has an IP69K ingress protection rating.
