Featured GA-A55-S3P主板 manuals
Gigabyte GA-A55-S3P Motherboard User Manual
This manual guides users through installing the GA‑A55‑S3P motherboard, configuring the BIOS, and installing necessary drivers. It includes safety precautions, connector descriptions, and detailed specifications for components such as CPU socket, memory, storage, and expansion slots.
The document also covers troubleshooting steps, CMOS reset, and warranty information, helping users maintain and service the motherboard safely and effectively. This manual is written in Chinese.
Covers: Hardware Installation · BIOS Settings · Driver Installation · Appendix · Product Specifications · Connector Overview
Gigabyte GA-A55-S3P Motherboard User Manual
This manual covers the hardware installation of the GA‑A55‑S3P motherboard, including safety precautions such as using an ESD wrist strap, unplugging power before handling, and proper handling of connectors. It also explains BIOS configuration, driver installation, and troubleshooting guidance.
Detailed product specifications are listed, describing supported processors, chipset, memory capacity, graphics output, audio codec, networking, expansion slots, storage interfaces, and USB ports. The appendix provides additional configuration notes and contact information for technical support.
Covers: Hardware Installation · Safety Precautions · BIOS Setup · Driver Installation · Product Specifications · Connector Layout
Latest GA-A55-S3P主板 manuals
Gigabyte GA-A55-S3P Motherboard User Manual
User Manual 44 pages · 11.7 MB · ZHThe Gigabyte GA‑A55‑S3P motherboard user manual provides hardware installation, BIOS setup, and driver installation instructions.
Gigabyte GA-A55-S3P Motherboard User Manual
User Manual 44 pages · 11.7 MB · ENThe Gigabyte GA-A55-S3P motherboard user manual provides installation steps, BIOS setup, specifications, and safety information.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in GA-A55-S3P主板 manuals
How do I install the CPU on the GA‑A55‑S3P motherboard?
First locate the FM1 socket, align the CPU’s first pin (marked by a small triangle) with the socket’s triangle, apply thermal paste, and insert the CPU carefully before securing the socket latch.
How many SATA ports are available and what RAID modes are supported?
There are six SATA 3 Gb/s ports, and the board supports RAID 0, RAID 1, RAID 10, and JBOD configurations.
What safety precautions should be taken when installing the motherboard?
Unplug the power cord, wear an ESD wrist strap, handle the board by its edges, and avoid touching metal leads or connectors.
What memory type and capacity does the GA‑A55‑S3P support?
It has two DDR3 DIMM slots that support up to 16 GB of system memory, with speeds of 1866, 1600, 1333, or 1066 MHz.
