FLIR Manuals

ThermaCAM 525 is an infrared thermal imager that has automatic adjustment, temperature measurement, and heat map storage functions.

The FLIR GF320 is an infrared thermal imager that can be used for both gas leak detection and electrical inspection. It has excellent thermal sensitivity, allowing for real-time detection of even the smallest gas leaks. The thermal imager also features built-in video recording, digital camera, laser pointer, and GPS data for accurate positioning. It is designed to be lightweight and durable, making it suitable for various applications.

This document introduces the PTZ-35 MS and PTZ-50 MS thermal imagers produced by FLIR. These thermal imagers can be used for security and surveillance applications. They feature high resolution, clear thermal images, and advanced thermal imaging software. These imagers can be integrated with white light/low light cameras to provide sharp and clear thermal images. They have a compact and lightweight design, suitable for harsh environments, and can be integrated with existing CCTV systems through various installation methods. Thermal imagers have wide applications in security and surveillance.

ThermaCAM™ QuickReport User's Manual, provides a Quick Start Guide, Workflow, Installation, Supported File Formats, Window Elements and Toolbar Buttons, Connecting the Thermal Imager, Processing Files, Viewing Images, Analyzing Images, Adding and Editing Image Descriptions, Editing Text Annotations, Creating Reports, Troubleshooting, About FLIR Systems and Index.

FLIR Systems' new i5 is the smallest, lightest, and most affordable infrared camera on the market. It is incredibly easy to use and requires no prior experience. It really is a matter of 'point-shoot-detect' to obtain high-quality infrared images that will immediately give you the infrared information you need. Not magic. impressive technology. Infrared radiation (IR) is emitted by every object above a temperature of -273°C. The human eye cannot detect infrared radiation, but an infrared camera can. It can take pictures of objects to show the amount of heat they are emitting. Such pictures consist of a map of colours that show surface temperatures of the object. An infrared camera is an invaluable diagnostic tool in a variety of industries, as it can detect abnormally hot or cold areas or components. In other words, you can detect problems that are not normally visible with the naked eye. The benefits of infrared. An infrared camera is a powerful maintenance tool, as in many instances equipment failure is preceded by a period of increasing heat. An infrared camera is also an excellent building inspection instrument, it quickly scans and identifies problem areas that can't be seen by the naked eye. It is also used for repair verification and insurance purposes. An infrared camera gives you the following benefits: A small infrared revolution. A small infrared revolution. Detect hidden problems, make quick damage assessments and perform maintenance.

FLIR i-Series Point-and-Shoot Thermal Imaging Cameras Now More Powerful and More Rugged Still the Most Affordable Compact and Easy to Use Quality Thermal Images and Data

IRW-SERIES Infrared (IR) Windows Enable successful thermographic inspection programs for energized electrical installations

FLIR E-Series bx series infrared cameras offer superior thermal imaging up to 76,800 pixels (320x240) for better long-range accuracy and the highest level of point-and-shoot camera IR resolution.

FLIR T420 and T440 are high-performance infrared cameras with an on-board visual camera, thermal fusion, touchscreen, Wi-Fi connectivity, and interchangeable lens, plus MSX™ image enhancement and FOV match. Get maximum flexibility and efficiency out of 320 x 240 thermal imaging from our new T400 line:

FLIR T420bx & T440bx are high-performance infrared cameras with on-board visual camera, thermal fusion, touch screen, Wi-Fi connectivity, and interchangeable lens. They offer superior thermal imaging with sharp resolution at 76,800 pixels, allowing for accurate measurements from a distance. The new MSX™ Enhancement feature adds visible spectrum definition to IR images in real time, highlighting and orienting problem locations (T440bx only). The Field of View (FOV) Match option automatically matches the visible camera field of view to the IR FOV for better documentation. The compass feature adds camera pointing direction to every image for additional location documentation (T440bx only). The cameras support Wi-Fi connectivity, allowing for quick sharing of images and critical information to smartphones and tablets using the FLIR Tools Mobile app. They provide accurate temperature measurements calibrated within ±2°C or ±2% of reading. The temperature range goes up to 1202°F (650°C) and is suitable for insulation, HVAC, and building applications (T440bx model). The cameras also offer scalable picture-in-picture and thermal fusion, blending thermal and visible light images on-screen. They include humidity, dew point, and insulation alarms to alert the user when moisture is detected.

FLIR T620 and T640 are high-performance thermal imaging cameras with an on-board 5MP visual camera, interchangeable lens options with autofocus, and a large 4.3-inch touchscreen LCD. These thermal cameras combine excellent ergonomics with superior image quality, providing the ultimate image clarity and accuracy, plus extensive communication possibilities. The highest IR resolution in its class delivers crisp thermal images with 307,200 pixels (640 × 480) for the best detection, pictures, and temperature measurements from long range. New! MSX™ Enhancement – Multi-Spectral Dynamic Imaging adds visible spectrum definition to IR images in real time for excellent thermal detail that instantly highlights problem locations. New! Field of View (FOV) Match – Option to match the visible camera field of view to the IR FOV for better documentation. New! GPS – Automatically adds location data to images for including in reports. Programmable Button – Provides easy access to favorite functions. Wi-Fi Connectivity – Send images and data to smartphones and tablets and share critical information quickly with the FLIR Tools Mobile for Apple® and Android™, featuring live video streaming and remote control via the mobile device. Accuracy – Calibrated within +/- 2°C or +/- 2% of reading. High Temperature Range – measures to 3632°F (2000°C) targeting electrical/industrial applications (T620 to 1202°F/650°C). Scalable P-i-P and Thermal Fusion – Blend thermal with visible light image.

FLIR B200 B-Series Infrared Camera is a high resolution infrared imager with an onboard visual camera, scalable picture-in-picture fusion, touch screen LCD and interchangeable lens
